Physical Description

The TimeSource 2700 consists of a shelf, an antenna with a cable,
mounting hardware, and software.
The shelf can be mounted on a wall or in an industry-standard
19 inch or 23 inch rack. In a rack, the shelf occupies two rack
units (RU). Except for the antenna connector, all connectors and
indicators are on the front of the shelf.
Two types of antennas are available: the magnetic-mount antenna
and the high-gain antenna.
The magnetic-mount antenna (Figure 1) consists of a receiving
element, a magnetic base, and 12 feet of coaxial cable with an
SMA connector. Because the antenna has a magnetic base, the
antenna can be located on any convenient metal structure, such
as an equipment rack or cable tray.
Warning:
magnetic-sensitive media (e.g., floppy or hard disks).
The high-gain antenna (Figure 2) consists of a high-gain antenna,
12 feet of LMR-240 cable with SMA and N connectors, and
hardware for mounting the antenna to a cable runway.
S S S S S S S S
Keep the magnetic-mount antenna away from
S S S S S S S S S S S S S S S S
15
