Chapter 2
System Components
Hardware Components and Accessories (continued)
HAWK MV-4000 Cables, Smart Series Illuminator Control Cable, and Power Supply
HAWK MV-4000 X-CODE Ethernet Port Cables
61-9000134-01 Cable, HAWK MV-4000 Ethernet, X-CODE / RJ45 CAT 6A, 1 m
61-9000134-02 Cable, HAWK MV-4000 Ethernet, X-CODE / RJ45 CAT 6A, 3 m
61-9000134-03 Cable, HAWK MV-4000 Ethernet, X-CODE / RJ45 CAT 6A, 5 m
HAWK MV-4000 VGA / USB Port Connector Cables
61-9000143-01 Cable, HAWK MV-4000 M12 to USB Socket, 1 m
61-9000147-01 Cable, HAWK MV-4000 M12 to VGA and USB, 1 m
HAWK MV-4000 Digital I/O Port Connector Cables
61-9000132-01 Cable, Adapter, HAWK MV-4000 to Accessory Cables / Power Supply (Supplied with camera)
61-9000151-01 Cable, HAWK MV-4000 M12 to Flying Leads, 3 m (No Adapter Required)
QX-1 Interface Cables and Accessories
61-000162-02 QX Cordset, HAWK MV-4000 Adapter to QX-1 M12 Plug (Screw-On), 1 m
61-000148-02 QX Cordset, HAWK MV-4000 Adapter to QX-1 M12 Plug (Screw-On), 3 m
98-000103-02 QX-1 Interface Device
99-000020-02 QX Photo Sensor, M12 4-Pin Plug, NPN, Dark On, 2 m
99-000020-01 QX Photo Sensor, M12 4-Pin Plug, NPN, Dark Off, 2 m
20-610024-01 Trigger Connector, 4-Pin Plug (Screw Terminal, Field-Wireable) (Self-Wiring)
Smart Series Illuminator Control Cables
61-9000135-01 Y Cable, HAWK MV-4000 Adapter to Smart Series Illuminator and QX-1, Power, 1 m
61-9000137-01 Y Cable, HAWK MV-4000 Adapter to Smart Series Illuminator and QX-1, Strobe, 1 m
61-000204-01 Cable, QX-1 to Smart Series Illuminator, Continuous Power
61-000218-01* Cable, QX-1 to Smart Series Illuminator, Strobe
Power Supply
97-000012-01 Power Supply, 100-240VAC, +24VDC, M12 12-pin Socket
HAWK MV-4000 and Smart Series Illuminator Mount
Standard Mount
98-9000054-01 APG Mount, HAWK MV-4000 (Requires Universal Mount)
Smart Series Illuminator / HAWK MV-4000 Mounting Kits
98-9000120-01 Kit, Bracket, MAX 300 to HAWK MV-4000
98-9000121-01 Kit, Bracket, DOAL to HAWK MV-4000
98-9000122-01 Kit, Bracket, Ring 60 / 70 to HAWK MV-4000
98-9000123-01 Kit, Bracket, Ring 100 to HAWK MV-4000
98-9000137-01 Kit, Smart Series Pharmalite, HAWK MV-4000
2-4 HAWK MV-4000 Smart Camera Guide
