Appendix E
CloudLink Web HMI

Connecting

To launch CloudLink, use your favorite web browser and enter the address of your device
in the browser's address bar. For example, if you have a Microscan smart camera on your
network at address 10.20.1.123, you would enter:
If using a HAWK MV-4000, you can also type the name of the device, as in the example http://HAWK5E7420.
The HAWK MV-4000 has a dedicated VGA/USB connector for attaching either a touch
monitor or regular monitor with keyboad and mouse. You can open CloudLink locally on the
camera by starting the shortcut available on the smart camera desktop or via the smart
camera touch app. The actual address in this case is http://localhost.
CloudLink also works with Visionscape Software and with AutoVISION's Emulator.
To connect to a software-based job running in FrontRunner or AutoVISION:
First, be sure the job is running, and then type the following into your browser's address bar:
Note: You must specify port 8080 for a PC-based connection. If you are connecting to a
PC-based system from a different machine on the network, use the IP address or name of
the PC instead of the local host. For example, use http://10.20.1.234:8080 if the PC's IP
address is 10.20.1.234.
Once you press the Enter key, you should see the following home page:
E-2
Click the CloudLink Dashboard
icon to launch the application.
HAWK MV-4000 Smart Camera Guide
