The pinout for the digital I/O and power connector adapter cable is as follows:
Pin
Signal Name
1
Output Common
2
Analog Output
3
Output 3
4
Power
5
Trigger
6
Input Common
7
Input 2
8
Input 3
9
Input 1
10
Output 1
11
Ground
12
Output 2
To interface with this adapter cable connector, you can use either a Microscan accessory
cable or you can build your own. To build your own digital I/O and power cable, parts can
be purchased from:
Cable Information
Manufacturer
Phoenix Contact GmbH and Co. KG
Part Number
SAC-12P- MS/3.0-PVC SC0 Order No: 1554788
Description
Sensor/Actuator Cable, 12-Pos., Black PVC, Straight M12 SPEEDCON Plug on Free Conductor End, 3.0 m
HAWK MV-4000 Smart Camera Guide
HAWK MV-4000 General Specifications
C
C-9
