Connecting - Microscan Vision MINI Xi Smart Camera Manual

Appendix F
CloudLink Web HMI

Connecting

To launch CloudLink, use your favorite web browser and enter the address of your device
in the browser's address bar. For example, if you have a Microscan smart camera on your
network at address 10.20.1.123, you would enter:
CloudLink also works with Visionscape Software and with AutoVISION's Emulator.
To connect to a software-based job running in FrontRunner or AutoVISION:
First, be sure the job is running, and then type the following into your browser's address bar:
Note: You must specify port 8080 for a PC-based connection. If you are connecting to a
PC-based system from a different machine on the network, use the IP address of the PC
instead of the local host. For example, use http://10.20.1.234:8080 if the PC's IP address
is 10.20.1.234.
Once you press the Enter key, you should see the following home page:
F-2
Click the CloudLink Dashboard
icon to launch the application.
Vision MINI Xi Smart Camera Guide
