To clean connector ends:
Use a video microscope to inspect the connector. If it is dirty,
1
continue to step 2.
Touch the tip of an optical-grade solvent pen or swab
2
soaked in solvent to a dry, optical-grade wiper.
Rub the connector endface across the solvent spot, then
3
back and forth once across the dry area of the wipe or card.
Typically, one or two short strokes (~ 1 cm or ~0.4 in) are
sufficient to dry the endface.
Use a video microscope to inspect the connector. If
4
necessary, clean and inspect the connector again.
A different procedure is necessary to clean some
connector styles (for example, VF-45).

Protect Connectors

Always put protective caps on connectors that you do not use.
Clean the caps periodically with a swab or wipers and fiber optic
solvent.
