Fiber optic power meter fiber optic light source

Advertisement

Fiber Optic Light Source

Measuring dB Loss

1. Connect cables to FOM and FOS.
2. Connect cables to a coupling.
3. Plug FOM into DMM (red dot to de volts).
4. On DMM, select mVdc.
5. Select desired wavelength.
6. Turn on FOS; stabilize (20 minutes).
7. Record reference measurement.
8. Disconnect cables at the coupling.
PN 200618
©1996 Fluke Corporation. All ri g hts reseNed. Printed in U.SA
FOM, FOS-XXXX
Fiber Optic Power Meter
Quick Reference Card
LED PRODUCT
May 1996
FLUKE®
CLASSI
