1. Product Overview

1.2. RS950G Front Panel Description

Figure 1.5. RS950G Front Panel Description
Status
Power
Alarm LED
Quad Mode
PRP
Local, HSR 1,
HSR 2
Table 1.1. Status LEDs

1.3. Bottom Panel Description

Figure 1.6. Bottom Panel Description
RuggedCom® RuggedSwitch™
Colour Activity
Green Solid
Red Solid
Green Solid
Green Solid
Solid
Green
Blinking
Description
Power on.
Alarm condition exists.
Unit is in High Availability Seamless Ring (HSR) Quad Mode with three
other RS950G units in an inter-ring configuration.
Unit is in Parallel Redundancy Protocol (PRP) mode.
Active link.
Tx/Rx activity.
13 RS950G Installation Guide Rev 100
