4. Diagnostics
• DST Offset
• DST Rule
The menu presents a choice of whether to reset all or only the selected set of configuration
parameters to their factory default values:
Figure 4.8. Load Factory Defaults Dialog
Defaults Choice
Synopsis: { None, Selected, All }
This parameter allows the user to choose to load defaults to Selected tables (i.e. excluding
those listed above), which would preserve configuration of the tables that are critical for
basic communication and switch management applications, or to force All tables to default
settings.
It is possible to explicitly reset configuration items in the exceptional categories
listed above to their default values by using the "sql" command. Please refer to the
section entitled: "Upgrading Firmware and Managing Configurations".

4.6. Resetting the Device

This operation will warm-start the device after the user has confirmed the reset operation from
the Reset Device option.
Figure 4.9. Reset Device Dialog
ROS® v3.11User Guide 96 RMC30
