Appendix A. SNMP MIB Support
File Name
rcrcpoeAC.mib
rcrcrstpmibAC.mib
rcrcsysinfomibAC.mib
rcrctrapsmibAC.mib
rcrs232mibAC.mib
rcserialmibAC.mib
Table A.3. TITLE
The following is an example from an RS416 device that describes the way to find objects and
variations for supported MIBs:
RS416 running ROS®-CF52 Main v3.11 supports "ruggecomRcTrapsAC01".
RC-RUGGEDCOM-TRAPS-MIB-AC defines "ruggecomRcTrapsAC01" support for the
following groups from RUGGEDCOM-TRAPS-MIB:
ruggedcomGenericTrapGroup,
ruggedcomPowerSupplyGroup,
ruggedcomNotificationsGroup,
ruggedcomSecurityGroup
RUGGEDCOM-TRAPS-MIB lists following objects in ruggecomGenericTrapGroup:
ruggedcomGenericTrapGroup OBJECT-GROUP
OBJECTS {
genericTrapSeverity,
genericTrapDescription
}
Query result – walking through sysORTable from RS416:
1: sysORID.1 (OBJECT IDENTIFIER) ruggedcomSnmpv2AC
2: sysORID.2 (OBJECT IDENTIFIER) ruggedcomSnmpFrameworkAC
3: sysORID.3 (OBJECT IDENTIFIER) ruggedcomSnmpUserBasedSmAC
4: sysORID.4 (OBJECT IDENTIFIER) ruggedcomSnmpViewBasedAcmAC
5: sysORID.5 (OBJECT IDENTIFIER) ruggedcomIfAC
6: sysORID.6 (OBJECT IDENTIFIER) ruggedcomTcpAC
7: sysORID.7 (OBJECT IDENTIFIER) ruggedcomUdpAC
8: sysORID.8 (OBJECT IDENTIFIER) ruggedcomIpAC
9: sysORID.9 (OBJECT IDENTIFIER) ruggedcomRcIpAC
10: sysORID.10 (OBJECT IDENTIFIER) ruggedcomRcTrapsAC01
11: sysORID.11 (OBJECT IDENTIFIER) ruggedcomRcSysinfoAC01
12: sysORID.12 (OBJECT IDENTIFIER) ruggedcomBridgeAC
13: sysORID.13 (OBJECT IDENTIFIER) ruggedcomRstpAC
14: sysORID.14 (OBJECT IDENTIFIER) ruggedcomRcStpAC
15: sysORID.15 (OBJECT IDENTIFIER) ruggedcomLldpAC
16: sysORID.16 (OBJECT IDENTIFIER) ruggedcomRmonAC
17: sysORID.17 (OBJECT IDENTIFIER) ruggedcomqBridgeAC
18: sysORID.18 (OBJECT IDENTIFIER) ruggedcomLagAC
19: sysORID.19 (OBJECT IDENTIFIER) ruggedcomRs232AC
20: sysORID.20 (OBJECT IDENTIFIER) ruggedcomRcSerialAC
21: sysORDescr.1 (DisplayString) SNMPv2-MIB Agent Capabilities.
[53.4E.4D.50.76.32.2D.4D.49.42.20.41.67.65.6E.74.20.43.61.70.61.62.69.6C.69.74.
ROS® v3.11User Guide
MIB Name
RC-RUGGEDCOM-POE-MIB-AC
RC-RUGGEDCOM-STP-AC-MIB
RC-RUGGEDCOM-SYS-INFO-MIB-
AC
RC-RUGGEDCOM-TRAPS-MIB-AC RUGGEDCOM-TRAPS-MIB
RUGGEDCOM-RS-232-MIB-AC
RC-RUGGEDCOM-SERIAL-MIB-
AC
116
Supported MIB
RUGGEDCOM-POE-MIB
RUGGEDCOM-STP-MIB
RUGGEDCOM-SYS-INFO-MIB
RS-232-MIB
RUGGEDCOM-SERIAL-MIB
RMC30
