Security Messages For Port Authentication - RuggedCom RMC30 User Manual

Appendix F. Security Messages for Authentication
Message Name
SNMP Authentication
Failure
Table F.7. Configurable Options
F.2. Security Messages for Port Authentication
The port security feature is not available on all RuggedSwitch platforms. This
section is only applicable for the RuggedSwitch platforms that can support the port
security feature.
The following is the list of log and alarm messages related to port access control in ROS®:
• MAC Address Authorization Failure
• Secure Port X Learned MAC Addr on VLAN X
• Port Security Violated
MAC Address Authorization Failure
ROS® generates this alarm and logs a message in the syslog when a host connected to a
secure port in RuggedSwitch is communicating using a source MAC address which has not
been authorized by ROS®, or the dynamically learned MAC address has exceeded the total
number of MAC addresses configured to be learned dynamically on the secured port. This
message is only applicable when the port security mode is set to "Static MAC".
Message Name
MAC Address
Authorization Failure
Table F.8. Configurable Options
Secure Port X Learned MAC Addr on VLAN X
ROS® logs a message in the syslog and sends a configuration change trap when a MAC
address is learned on a secure port. Port X indicates the secured port number and VLAN
number on that port. This message is not configurable in ROS®.
Message Name
Secure Port X Learned MAC Addr on
VLAN X
Table F.9. Message Details
Port Security Violated
This message is only applicable when the security mode for a port is set to "802.1x or 802.1x/
MAC-Auth"
ROS® this alarm and logs a message in the syslog when the host connected to a secure port
tries to communicate using incorrect login credentials.
Message Name
802.1x Port
Authentication Failure
ROS® v3.11User Guide
Alarm
Yes
Alarm
Yes
SNMP Trap
Yes
Alarm
X Yes
137
SNMP Trap
Yes
SNMP Trap
Yes
Syslog
Yes
SNMP Trap
Yes
Syslog
Yes
Syslog
Yes
Syslog
Yes
RMC30
