Appendix C. List of Objects Eligible for RMON Alarms
Appendix C. List of Objects Eligible for RMON
Alarms
The following table lists ROS® database objects which are eligible for RMON alarms:
dot1dBasePortMtuExceededDiscards
dot1dTpPortInFrames
dot1dTpPortOutFrames
dot1qVlanNumDeletes
etherStatsBroadcastPkts
etherStatsCollisions
etherStatsCRCAlignErrors
etherStatsDropEvents
etherStatsFragments
etherStatsJabbers
etherStatsMulticastPkts
etherStatsOctets
etherStatsOversizePkts
etherStatsPkts
etherStatsPkts1024to1518Octets
etherStatsPkts128to255Octets
etherStatsPkts256to511Octets
etherStatsPkts512to1023Octets
etherStatsPkts64Octets
etherStatsPkts65to127Octets
ROS® v3.11User Guide
The number of frames discarded by this port due to an excessive
size.
The number of frames that have been received by this port from its
segment.
The number of frames that have been transmitted by this port to its
segment.
The number of times a VLAN entry has been deleted from the
dot1qVlanCurrentTable (for any reason). If an entry is deleted, then
inserted, and then deleted, this counter will be incremented by 2.
The number of good Broadcast packets received.
The best estimate of the total number of collisions on this Ethernet
segment.
The number of packets received which meet all the following
conditions:1. Packet data length is between 64 and 1536 bytes
inclusive.2. Packet has invalid CRC.3. Collision Event has not been
detected.4. Late Collision Event has not been detected.
The number of received packets that are dropped due to lack of
receive buffers.
The number of packets received which meet all the following
conditions:1. Packet data length is less than 642. Collision Event
has not been detected.3. Late Collision Event has not been
detected.4. CRC invalid.
The total number of packets received that were longer than 1518
bytes and had either a bad Frame Check Sequence or Alignment
Error.
The number of good Multicast packets received.
The number of bytes in received good packets (Unicast+Multicast
+Broadcast) and dropped packets.
The number of packets received with data length greater than 1536
bytes and valid CRC.
The number of received good packets (Unicast+Multicast
+Broadcast) and dropped packets
The total number of received packets that were between 1024 and
1518 bytes long.
The total number of received packets that were between 128 and
255 bytes long.
The total number of received packets that were between 256 and
511 bytes long.
The total number of received packets that were between 512 and
1023 bytes long.
The total number of received packets that were 64 bytes long.
The total number of received packets that were between 65 and 127
bytes long.
120 RMC30
