Appendix D. ModBus Management Support and Memory
Map
Address #Registers
0602 2
0604 2
0606 2
0640 2
0642 2
0644 2
0646 2
0680 2
0682 2
0684 2
0686 2
06C0 2
06C2 2
06C4 2
06C6 2
D.1.1. Text
This format provides a simple ASCII representation of the information related to the product.
ASCII characters' most significant byte of register comes first.
For example, consider a "Read Multiple Registers" request to read Product Identification from
location 0x0000.
0x04
The response may look like:
0x04 0x10 0x53
0x00 0x00 0x00
In this example, starting from byte 3 until the end, the response presents an ASCII
representation of the characters for the product identification, which reads as "SYSTEM
NAME". The length of this field is smaller than eight registers, so the rest of the field is filled
with zeros.
D.1.2. Cmd
This format instructs the device to set the output to either 'true' or 'false'. The most significant
byte comes first.
• FF 00 hex requests output to be True.
• 00 00 hex requests output to be False.
• Any value other than the suggested values does not affect the requested operation.
ROS® v3.11User Guide
Description (Reference Table in UI)
Port 2 Statistics – Serial In characters
Port 3 Statistics – Serial In characters
Port 4 Statistics – Serial In characters
Port 1 Statistics – Serial Out characters R
Port 2 Statistics – Serial Out characters R
Port 3 Statistics – Serial Out characters R
Port 4 Statistics – Serial Out characters R
Port 1 Statistics – Serial In Packets
Port 2 Statistics – Serial In Packets
Port 3 Statistics – Serial In Packets
Port 4 Statistics – Serial In Packets
Port 1 Statistics – Serial Out Packets
Port 2 Statistics – Serial Out Packets
Port 3 Statistics – Serial Out Packets
Port 4 Statistics – Serial Out Packets
0x00 0x00
0x59 0x53 0x54
0x00 0x00
0x00
0x45 0x4D 0x20 0x4E
129
R/W Format
R Uint32
R Uint32
R Uint32
Uint32
Uint32
Uint32
Uint32
R Uint32
R Uint32
R Uint32
R Uint32
R Uint32
R Uint32
R Uint32
R Uint32
0x08
0x41 0x4D 0x45
