4.2 Continuous Measurement Settings

1 Click icon at lower left corner of "BASIC" screen, click
"Capture function", "Continuous", "Yes".
Click icon at bottom center of screen to back to "BASIC"
indicators with icon ② change to "
3 Point optical sensor to light source.
4
※ Status indicator spin
continuously in case the
continuous measurement
is in progress.
Auto measurement at frequency
of once every 3 seconds.
Press measure key or click
measurement button at bottom
center of screen to start
continuous measurement.
1. Users cannot save the measurement data while processing
continuous measurement.
Adjust the integration time is only allowed in the manual
2.
27
mode.
2
".
5 6
Click measurement button or
press measure key again to
stop continuous measurement.

5.1 Connecting with Mobile APP

WiFi Wing wireless remote control card
Insert WiFi Wing card to the system. At IOS or Android
platform, download PG100N APP and install it on your mobile.
Then you can connectit with system for the measurement of
wireless control.
※ For more operation, please refer to Wing user manual. Please visit UPRtek official
site, http://www.uprtek.com → Support → Download Center.
Install APP
Download and install the PG100N APP on your Mobile.
Select WiFi UPRtek_Wing.
Measure
WiFi connection
WiFi Wing
wireless remote control card
( It is used to connect with APP.)
PG100N
UPRtek_Wing
