4.1 Measurement Settings

In mode of "BASIC", "SPECTRUM", "PPFD", "PFD", "CIE" you
may click icon at lower left corner for settings in details.
Previous
page
measurement page
■ Save format ■ Auto save
You may opt to save Opt to select auto save
measurement data of measurements or not.
Excel file only or both
Excel and JPG files.
■ Integration time
Exposure time may set in unit of
microsecond (0.001 second). Valid
range: 2~1000ms at step of ±1ms
when exposure time is less than
100ms and ±20ms otherwise.
25
Previous
page
Back to
■ Integration mode
Select auto or manual
mode. Exposure time
need be set in case
manual mode is chosen.
4.1 Measurement Settings
■ Capture function ■ Operation sound
Select for one time or Select to on/off operation
continuous measurement. sound. Set operation
In case continuous sound on to beep once
measurement is set, after measurement
press Measurement / operation (enabled by
Local Measurement key pressing the Measurement
to start auto measurement / Local Measurement
at frequency of once per key) completed.
3 seconds. Press
Measurement / Local
Measurement key again
to stop continuous
measurement. (See
Section 4.2: Continuous
measurement for
reference.)
About auto save:
Measurements are auto saved (Excel + JPG) in case this
1.
operation is set on. In case there is no SD card inserted
when measurement is running, this product prompts warning
messages while keep on measuring.
Measurements are saved only by clicking Save icon in case
2.
this operation is set off.
■ Dark calibration
This product is default
to run background
calibration after power
on. This operation enables
running background
calibration any time.
