2.2 Taking a Measurement
Measurement
Click "BASIC" mode to enter measurement page.
1 Point optical sensor to light source to be tested.
2
Press the measurement button at
bottom center of screen or the
measurement key at left hand side
to measure.(You can press
11
measurement key at both sides.)
3
This product beeps once after
measurement is done and
displays results on screen.
2.2 Taking a Measurement
Save measurement data
1 2
Press the setup button Click "Save file"
at lower left corner.
.xls
4
▲You may save entire source data.
.JPG
Measurement data is
now saved in SD card.
You may note down
file name if necessary.
▲You may save measurement screen in "BASIC mode",
"SPECTRUM mode", "PPFD mode", "PFD mode" and
"CIE 1931.1976 mode".
3
EXCEL file name：
ESPDY Y Y Y _ M M D D _ H H M M S S
regular ( year ) (month)(day) (hour/min/seconds)
JPG file name：
I MG Y Y Y Y _ M M D D _ H H M M S S
regular ( year ) (month)(day) (hour/min/seconds)
