5.2 Connecting with uSPECTRUM

I
nstall uSPECTRUM PC software
Please visit UPRtek official site, http://www.uprtek.com→
Support→Download Center, Download and install uSPECTRUM
software on the PC. Then you can connect it with the system
for USB control of measurement.
uSPECTRUM
Install file
Set USB PC connection mode
You may connect this product to a Windows PC with USB
(rather than Type-C USB) cable.
Note: Please select PC connection in USB mode in items of
OPTION mode.
Mass storage：
Save measurement data in SD
card of PG100N.
Select "OPTION". Select "USB mode".
29
PC connection：
Connection PG100N to PC via
USB cable for measurement
use with LIGHT ANALYZER.
Select "PC connection"
and perss Yes.
5.2 Connecting with uSPECTRUM
Measure
After connection, the PG100N screen will display as shown.
USB connection
uSPECTRUM PC software
30
