When the Routine is activated and data is acquired, the Analysis window will display the real-
time graph of this analysis.
Example 1
To plot the mean of data, with Measurement cursor m[1] configured as 'Mean', select
'm[1]' from the Y-Axis list. The Equation field is populated as:
The X-Axis (and its Equation) should be set as 'time' and its Units as 's'.
Example 2
To plot the amplitude of measurement cursor #1 minus measurement cursor #2, enter
the Y-Axis equation as:
Adjust the Y-Axis Units if needed.
The X-Axis and Equation defaults are 'time', and the Units default is 's'.
Free-form Equations
Various variables, special identifiers, and constants, are available for use in equations. See the
Equation Editor section for details and examples, along with parsing and syntax information.
m[1]
m[1] - m[2]
