Read Rate

Read Rate

Click the Utilities button and then the Read Rate tab
to display the Read Rate view.
Read Rate information is displayed in
the lower portion of the Utilities view.
Serial commands can also be sent to
the scanner from this screen.
Important: When Read Rate is enabled, the
regardless of how the scanner is configured.
7-4
To see the number of decodes per second,
click the Decodes/sec radio button and
then the Start button.
To see the percentage of decodes, click
the Percent radio button and then the Start
button.
To end a Read Rate test, click the Stop
button (the Start button becomes a Stop
button during an active Read Rate test.)
Configuration Database
QX-870 Industrial Raster Scanner User Manual
is not active,
