Specifications; System Dimensions; Environmental Operating And Storage Conditions - Signostics uscan User Manual

7. S
PECIFICATIONS

System dimensions

Table 7.1 Dimensions of probe
Component
Ultrasound probe
Table 7.2 Dimensions of cable
Component
Connecting cable, handheld display
Connecting cable, tablet display
Table 7.3 Dimensions of displays
Component
Tablet
Handheld

Environmental Operating and Storage Conditions

The Uscan is intended to be used and stored in normal ambient conditions inside a medical facility.
Table 7.4 Operating, charging, transport and storage condition ranges for Uscan
Temperature (°C)
Relative humidity (non-condensing)
Pressure
Table 7.5 Charging condition ranges for Uscan
Temperature (°C)
Relative humidity (non-condensing)
Pressure
P003948
Height
147mm
(5.78 inches)
Length
Height
207mm
(8.15 inches)
159.3mm
(6.27 inches)
Operating
5 (41°F) – 40°C (104°F)
40 °C (104°F)
5°C (41°F)
15–90%
70–101.5 kPa (10.3-14.7 psi)
Charging
5 (41°F) – 40°C (104°F)
40 °C (104°F)
5°C (41°F)
20–80%
70–101.5 kPa (10.3-14.7 psi)
Uscan User Manual
Width Depth
62mm 33mm
(2.44 inches) (1.3 inches)
900mm (35.43 inches)
1800mm (70.9 inches)
Width Depth
137mm 8mm
(5.39 inches) (0.31 inches)
77.8mm 7.3mm
(3.06 inches) (0.29 inches)
Transport and Storage
-20 (-4°F) – 50°C (122°F)
-20°C (-4°F)
10–93%
50–101.5 kPa (7.3-14.7 psi)
Weight
~200g
(7.1 oz)
Weight
350g
(12.3 oz)
179g
(6.3 oz)
50 °C (122°F)
Page | 40
