 Orientation Mark – corresponds to the Scan button orientation on the probe.
 Done – tap to end and save the exam.
 Scan (Stop) – tap to start (unfreeze) and stop (freeze) scans.
 Exam Icons – are displayed depending on the context of the exam. Icons include help, print, measure,
movie, delete, and a menu to access other functions (Annotations, Notes). Tap to activate the function
associated with the icon.
 Scan Preset Menu – tap to change to a different scan preset.
 Measurement Area – area for displaying caliper measurements.
 Ultrasound Image – area for displaying ultrasound images.
 Image Thumbnails – will be displayed for multiple images in an exam. Tap a thumbnail to view an
image.
