Do not fan too fast. As a guideline a complete

fan should take around 3- 5 seconds.
Do not twist the transducer.

Angle the probe so the bladder is in the middle

of the ultrasound image.
 During acquisition, the display will show the fan
position. When the three dimensional data acquisition is
complete, the system automatically completes the scan
and displays the measured volume
A movie of the complete bladder acquisition is displayed.
Bladder Measurement Correction
Correct errors outlining the bladder as follows:
 Tap the Pencil icon (
 Tap the Pencil Redraw icon (
outline and redraw; or
 Touch the bladder outline to adjust the existing outline.
A drag circle will appear. Drag the outline to align with
the bladder wall. Adjusted outlines change color to blue
(see Fig 3.13).

For fine adjustments, zoom in to enlarge the image then
adjust the outline.
 Tap the Play icon
check other images. Every image in a measurement can
be adjusted if required.
 If a bladder has been outlined where no bladder is
present, then drag the progress marker
the bladder, tap
 Tap End Editing to finish.

Audio Feedback

The Uscan provides audio feedback during bladder measurement as follows:
 A short double beep sounds when the system has detected a bladder and the user can start the fan of
the probe
 A buzzer sounds if a user starts fanning the probe before the system has found the bladder
 A chime sounds when the system expects the user to change direction of the fan
 A beep sounds at the completion of a successful scan
 A decaying tone sounds at the completion of a 0ml scan

Common Functions

Multiple Scans
Simply tap the Scan
or ultrasound scans to the exam.
P003948
(Fig 3.12).
) to start outline editing.
) to delete the existing
or drag the progress marker
and select Mark Bladder End.
icon or click the probe Scan button
Uscan User Manual
to
to the end of
to add more bladder volume measurements
Fig 3.11 Acquire data
Fig 3.12 Measured volume
Fig 3.13 Adjusting outline
Page | 27
