1. I I
MPORTANT NFORMATION
About the User Manual
This User Manual is a reference tool for users of the Uscan; it does not constitute medical advice nor provide
clinical training, instruction in exam protocols, or information on how to interpret scans.
This manual should be read before Uscan is used. The Uscan is intended to be used in a medical facility.
Manual conventions
The following style conventions are used in this manual:
 Buttons found on your Uscan are indicated in bold italics, e.g., Scan button. This style is also used to
describe areas of the display touch screen, e.g., Image name.
 "Tap" refers to touching the screen quickly with your finger.
 "Click" refers to pressing and releasing the button on the probe unit.
 "Drag" refers to touching the screen with your finger and then moving your finger across the screen.
 "Swipe" refers to moving your finger across the screen quickly.
 "Pinch" refers to moving two fingers in a pinch motion or pinch release motion across the screen.
 "Check" refers to tapping a checkbox to enable the associated function.
 "Uncheck" refers to tapping a checkbox to disable the associated function.
 "Select" refers to tapping a menu item from a menu list.
 New terms that describe functions for the App are introduced in italics, e.g., exam.
 Numbered steps must be performed in a specific order.
 Bulleted items are lists in no specific order.
 Links to other sections within the manual appear colored and underlined, e.g., see
(page 12).
Version information
This User Manual applies to Uscan with software version V3.5.x
Warnings, Cautions and Contraindications
A Warning describes precautions a user should take to prevent injury or loss of life.
A Caution describes precautions a user should take to prevent damage to the device.
A Contraindication is a specific situation in which the device should not be used because it may be harmful to
the patient.
Warnings, cautions and contraindications are included throughout this manual along with the content to which
they apply. In addition all warnings and cautions are listed in the
(page 8).

Product Description

The Uscan consists of a Uscan display running a Signostics App, connected to a Uscan probe via a cable. The
system has been designed for non-invasive urological imaging examinations, and enables users to non-
invasively perform general abdominal imaging and measurements at the point-of-care. The Uscan generates
and transmits ultrasound energy in the form of pulses in the 3 to 7MHz range into a patient, detects the
reflected pulses, and processes the information in order to generate ultrasound images and measure anatomical
structures.
P003948
Cautions, Warnings and Contraindications
Uscan User Manual
Contact information
Page | 1
