1.

Introduction

1.1

Features

The ATmega328PB Xplained Mini evaluation kit provides a development platform for the ATmega328PB.
Key Features
• On-board debugger with full source-level debugging support in Atmel Studio
• Auto-ID for board identification in Atmel Studio
• Access to all signals on the target MCU
• One green mEDBG status LED
• One yellow user LED
• One mechanical user push button
• Two QTouch
• Virtual COM port (CDC)
• External target CLK 16 MHz at 5V, 8 MHz at 3.3V
• USB powered
• 3.3V regulator
• Arduino shield compatible footprints
• Target SPI bus header footprint
• Xplained Pro extension headers can easily be strapped in
1.2

Board Overview

A brief overview of the default kit configuration, headers, and connectors.
©
2017 Microchip Technology Inc.
®
buttons
ATmega328PB Xplained Mini
User Guide
DS50002660A-page 4
