5.

Hardware Revision History and Known Issues

This user guide provides the latest available revision of the kit. This chapter contains information about
known issues, a revision history of older revisions, and how older revisions differ from the latest revision.
5.1

Identifying Product ID and Revision

The revision and product identifier of Xplained Mini boards can be found in two ways; either through
Atmel Studio or by looking at the sticker on the bottom side of the PCB.
By connecting an Xplained Mini board to a computer with Atmel Studio running, an information window
will pop up. The first six digits of the serial number, which is listed under kit details, contain the product
identifier and revision.
The same information can be found on the sticker on the bottom side of the PCB. Most kits will print the
identifier and revision in plain text as A09-nnnn\rr, where nnnn is the identifier and rr is the revision.
Boards with limited space have a sticker with only a data matrix code, which contains a serial number
string.
The serial number string has the following format:
"nnnnrrssssssssss"
n = product identifier
r = revision
s = serial number
The product identifier for ATmega328PB Xplained Mini is A09-2523.
5.2

Revision 4

There are no known issues with revision 4 of ATmega328PB Xplained Mini.
5.3

Revision 3

Revision 3 is the initial released revision.
©
