Figure 1-1. ATmega328PB Xplained Mini Headers and Connectors
CDC UART
(J104)
NC
Power (J202)
VCC
RESET
3V3
5V
GND
GND
VIN
PC0
Analog I/O (J203)
PC1
PC2
PC3
PC4
DIGITAL J200
DIGITAL J200
PC5
Table 1-1. Default Configurations
Function
Kit power source (J300)
Target power (J301)
ATmega328PB clock
Info:
Changing the default settings require modification of the kit using a soldering iron.
1.
Details on how to change the power settings are described in
2.
Details on the mEDBG clock are described in
3.
Debugging through debugWIRE may be disabled if the internal oscillator is used.
©
2017 Microchip Technology Inc.
Power source
Status
Micro USB
(J300)
LED
Con nector
PB7
QTouch
User
SPI
Bu ttons
button
(J204)
Default configuration
5.0V USB powered
5.0V USB powered
16 MHz mEDBG clock
User Guide
ATmega328PB Xplained Mini
Target power
mEDBG
(J301)
(ATmega32U4)
PB5
User
External
mega328PB
LED
Clock
Other settings
External input VIN
3.3V from on-board regulator
(2)
Internal oscillator
Xplained Mini Clock
Power
Ground
Target I/O
Shared I/Os
Digital I/O High (J200)
PC5
ANALOG (J203)
PC4
ANALOG (J203)
AREF
GND
PB5
LED / ISP (J204)
PB4
ISP (J204)
PB3
ISP (J204)
PB2
PB1
PB0
PD7
Digital I/O Low (J201)
PD6
PD5
PD4
PD3
PD2
PD1
CDC RX
PD0
CDC TX
(1)
(1)
(3)
Power
Sources.
Output.
DS50002660A-page 5
