1.

Introduction

1.1

Feature list

• ATSAMB11ZR-210CA module
• Bluetooth
• One mechanical reset button
• One mechanical programmable button
• One user LED (yellow)
• Battery header (1x2 100mil header)
• 32.768 kHz crystal
• Two Xplained Pro extension headers
• Embedded Debugger
– Auto-ID for board identification in Atmel Studio
– One status LED (yellow)
– One power LED (green)
– Symbolic debug of complex data types including scope information
– Programming and debugging, including power measurements
– Data Gateway Interface (DGI): SPI, I
– Virtual COM port (CDC)
• Embedded current measurement circuitry with support for data visualization
• USB-powered
• Supported with application examples in Atmel Software Framework
1.2

Kit Overview

The SAM B11ZR Xplained Pro evaluation kit is a hardware platform used to evaluate the
ATSAMB11ZR-210CA module.
The kit offers a set of features that enable the user to get started with the ATSAMB11ZR-210CA module
peripherals right away, and to understand how to integrate the device in their own design.
©
2017 Microchip Technology Inc.
®
host and Device mode
2
C, four GPIOs
User Guide
ATSAMB11ZR
DS70005334A-page 3
