4.2.6
Temperature Sensor
The SAM B11ZR Xplained Pro has an on-board temperature sensor AT30TSE758A, powered by the
VCC_TARGET_P3V3 of the board. The temperature sensor is I²C controlled and is available on the
address 0x48 (7-bit MSB address).
AT30TSE758A also has a serial EEPROM accessible through I
SAMB11 pin
LP_GPIO_8
LP_GPIO_9
AO_GPIO_2
4.2.7
Crypto Authentication Device
The SAM B11ZR Xplained Pro has a Crypto Authentication Device (ATECC508A) connected to the I
bus. The table below shows all the connections between the ATECC508A and ATSAMB11ZR-210CA
module.
Table 4-10. ATECC508A Connections
SAMB11 ZR pin
4
5
4.3
Embedded Debugger Implementation
SAM B11ZR Xplained Pro contains an Embedded Debugger (EDBG) that can be used to program and
debug the ATSAMB11ZR using Serial Wire Debug (SWD). The Embedded Debugger also includes a
Virtual Com port interface over UART, a Data Gateway Interface (DGI) over SPI, and I
includes four of the SAM B11ZR GPIOs. The kit also includes a XAM extension processor to the
Embedded Debugger for on-board current measurement. Atmel Studio can be used as a front-end for the
Embedded Debugger.
4.3.1
Serial Wire Debug
The Serial Wire Debug (SWD) uses two pins to communicate with the target. For further information on
how to use the programming and debugging capabilities of the EDBG, see
Table 4-11. SWD Connections
SAM B11ZR pin
LP_GPIO_0
LP_GPIO_1
4.3.2
Virtual COM Port
The Embedded Debugger acts as a Virtual Com Port gateway by using one of the ATSAMB11ZR UARTs.
For further information on how to use the Virtual COM port, see
©
2017 Microchip Technology Inc.
Function
SDA (Data line)
SCL (Clock line)
ALERT
ATECC508A pin
Function
5
UART2_CTS/I2C1_SDA
6
UART2_RTS/I2C1_SCL
Function
SWD clock
SWD data
User Guide
ATSAMB11ZR
2
C.
Shared functionality
EXT1,
EDBG I²C
EXT1,
EDBG I²C
EXT1, EXT3
Shared Functionality
DEBUG
DEBUG
2
C , and also
Embedded
Debugger.
Embedded
Debugger.
2
C
I²C,EXT3
I²C,EXT3
DS70005334A-page 17
