Table 4-7. Mechanical Buttons
ATmega4809 Pin
PB2
PF6
4.3.3 LED
There is one yellow LED available on the ATmega4809 Xplained Pro board that can be turned ON and
OFF. The LED can be activated by driving the connected I/O line to GND.
Table 4-8. LED Connection
ATmega4809 Pin
PB5
4.3.4 ATECC508A
ATmega4809 Xplained Pro has one
the connections between the ATECC508A and the ATmega4809.
Info: The I
Table 4-9. ATECC508A Connections
ATECC508A Pin
1 [NC]
2 [NC]
3 [NC]
4 [GND]
5 [SDA]
6 [SCL]
7 [NC]
8 [VCC]
9 [PAD]
4.4

Embedded Debugger Implementation

ATmega4809 Xplained Pro contains an Embedded Debugger (EDBG) that can be used to program and
debug the ATmega4809 using the UPDI interface. The Embedded Debugger also includes a Virtual Com
port interface over UART, a Data Gateway Interface over SPI, and I
ATmega4809 GPIOs. Atmel Studio can be used as a front-end for the Embedded Debugger.
©
2018 Microchip Technology Inc.
Silkscreen Text
SW0
SW1/RESET
Function
Yellow LED0
ATECC508A
2
C address is 0x60 (7-bit, right adjusted without R/W bit).
ATmega4809 Pin Function
- -
- -
- -
- GND
PC2 TWI0 SDA
PC3 TWI0 SCL
-
- VCC_TARGET
- GND
ATmega4809 Xplained Pro
Shared Functionality
EXT2, DGI GPIO0
EXT2, DEBUG,
Shared Functionality
EXT2, DGI GPIO3
CryptoAuthentication device. The table below shows all
Shared Functionality
-
-
-
-
EXT1, EXT2, EXT3, mikroBUS,
EXT1, EXT2, EXT3, mikroBUS,
-
-
-
2
C, and it includes four of the
User Guide
Hardware User Guide
EDBG
EDBG DGI
EDBG DGI
DS50002716A-page 18
