3 Negative
Chassis Ground Provides an optional connection for microphone shield wire to
Screw chassis ground.
LED Indicators Power: Power over Ethernet (PoE) present
Note: Use a PoE injector if your network switch does not supply PoE.
Network: Network connection active
Network Audio: Dante audio present on the network
Note: Error details are available in the event log in the web application.
LED Status
Off
Green
Red
Encryption:
LED Status
Off
Green
Red
Dante Network Connects to a network switch to send Dante audio, while receiving
Port Power over Ethernet (PoE) and data from the control software. See
the
Reset Button Resets the device settings back to the factory default.
Power Over Ethernet (PoE)
This device requires PoE to operate. It is compatible with both Class 0 and Class 3 PoE
sources.
Power over Ethernet is delivered in one of the following ways:
A network switch that provides PoE
A PoE injector device
Activity
No active signal
Device is operating
successfully
Error has occurred. See
event log for details.
Dante and networking section for additional information.
9/12/17, 9(22 AM
Activity
Audio not encrypted
Successful encrypted audio
connection with another device
Encryption error. Possible
causes:
Encryption is enabled on
one device and not on
another
Passphrase mismatch
