ANI22 Response:
< REP LIMITER_ENGAGED ON >
< REP LIMITER_ENGAGED OFF >
Get Encryption Status
Command String:
< GET xx ENCRYPTION_CH >
ANI22 Response:
< REP xx ENCRYPTION_CH ON >
< REP xx ENCRYPTION_CH OFF >
Get Phantom Power Status
Command String:
< GET xx PHANTOM_PWR_ENABLE >
ANI22 Response:
< REP xx PHANTOM_PWR_ENABLE ON >
< REP xx PHANTOM_PWR_ENABLE OFF >
Turn Phantom Power On/Off
Command String:
< SET xx PHANTOM_PWR_ENABLE ON >
< SET xx PHANTOM_PWR_ENABLE OFF >
ANI22 Response:
< REP xx PHANTOM_PWR_ENABLE ON >
< REP xx PHANTOM_PWR_ENABLE OFF >
Reboot ANI22
Command String:
< SET REBOOT >
ANI22 Response:
< REP REBOOT >
Get Error Events
Command String:
< GET LAST_ERROR_EVENT >
ANI22 Response:
< REP LAST_ERROR_EVENT
{ yyyyyyyyyyyyyyy } >
Get PEQ Filter Enable
Command String:
The ANI22 will respond with one of these
strings.
The ANI22 will respond with one of these
strings.
The ANI22 will respond with one of these
strings.
Send one of these commands to the ANI22.
The ANI22 will respond with one of these
strings.
Gets the last error that is loged on the
ANI22.
Where yyyyyyyyyyyyyyy is up to 128
characters.
Where xx is the PEQ block 01-04. Where
