Output Impedance
150 Ω
Input Clipping Level
Analog Gain Setting= +0 dB
Analog Gain Setting= +27 dB
Analog Gain Setting= +51 dB
Analog Output Level
Selectable Line 0 dB
Aux - 20 dB
Mic -46 dB
Built-in Digital Signal Processing
Per Equalizer (4-band Parametric, Dante Channels Only), Mute, Limiter, Gain
Channel (140 dB range)
System Channel Summing
Networking
Cable Requirements
Cat 5e or higher (shielded cable recommended)
Accessories
Furnished Accessories
Hardware kit (XLR model)
Hardware kit (block connector model) 90B33522
Mounting Bracket (1/3 rack unit)
Optional Accessories and Replacement Parts
19" rack tray CRT1
+20 dBV
-7 dBV
-31 dBV
90A29254
53A27742
