ANI22 Response:
< REP HW_GATING_LOGIC ON >
< REP HW_GATING_LOGIC OFF >
Get Mic Logic LED In
Command String:
< GET CHAN_LED_IN_STATE >
ANI22 Response:
< REP CHAN_LED_IN_STATE ON >
< REP CHAN_LED_IN_STATE OFF >
Set Mic Logic LED In
Command String:
< SET CHAN_LED_IN_STATE ON >
< SET CHAN_LED_IN_STATE OFF >
ANI22 Response:
< REP CHAN_LED_IN_STATE ON >
< REP CHAN_LED_IN_STATE OFF >
Get Input Meter Display Mode
Command String:
< GET INPUT_METER_MODE >
ANI22 Response:
< REP INPUT_METER_MODE PRE_FADER >
< REP INPUT_METER_MODE POST_FADER
>
Set Input Meter Display Mode
Command String:
< SET INPUT_METER_MODE PRE_FADER >
< SET INPUT_METER_MODE POST_FADER
>
ANI22 Response:
< REP INPUT_METER_MODE PRE_FADER >
< REP INPUT_METER_MODE POST_FADER
>
Important Product Information
The equipment is intended to be used in professional audio applications.
Note: This device is not intended to be connected directly to a public internet network.
The ANI22 will respond with one of these
strings.
The ANI22 will respond with one of these
strings.
Send one of these commands to the ANI22.
The ANI22 will respond with one of these
strings.
The ANI22 will respond with one of these
strings.
Send one of these commands to the ANI22.
The ANI22 will respond with one of these
strings.
