AUX_LVL >
< REP xx AUDIO_OUT_LVL_SWITCH
MIC_LVL >
Flash Lights on ANI22
Command String:
< SET FLASH ON >
< SET FLASH OFF >
ANI22 Response:
< REP FLASH ON >
< REP FLASH OFF >
Turn Metering On
Command String:
< SET METER_RATE sssss >
ANI22 Response:
< REP METER_RATE sssss >
< SAMPLE aaa bbb ccc ddd >
Stop Metering
Command String:
< SET METER_RATE 0 >
ANI22 Response:
< REP METER_RATE 00000 >
Get LED Brightness
Command String:
< GET LED_BRIGHTNESS >
ANI22 Response:
< REP LED_BRIGHTNESS n >
Set LED Brightness
Command String:
Send one of these commands to the ANI22.
The flash automatically turns off after 30
seconds.
The ANI22 will respond with one of these
strings.
Where sssss is the metering speed in
milliseconds. Setting sssss =0 turns
metering off. Minimum setting is 100
milliseconds. Metering is off by default.
Where aaa, bbb, etc is the value of the
audio level received and is 000-060.
aaa = input 1
bbb = input 2
ccc = output 1
ddd = output 2
A value of 00000 is also acceptable.
Where n can take on the following values:
0 = LED disabled
1 = LED dim
2 = LED default
Where n can take on the following values:
