WIRELESS SYSTEM
MICROFLEX
WIRELESS
AUDIO NETWORK INTERFACE
USER GUIDE
© 2015 Shure Incorporated
27A20456 (Rev. 3)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MICROFLEX MXWANI8 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Shure MICROFLEX MXWANI8

  • Page 1 WIRELESS SYSTEM MICROFLEX WIRELESS AUDIO NETWORK INTERFACE USER GUIDE © 2015 Shure Incorporated 27A20456 (Rev. 3)
  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 14. REFER all servicing to qualified service personnel. Servicing is required when the ap- paratus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been READ these instructions.
  • Page 3: General Description

    • Built-in gigabit network switch with four ports (mic/line/aux) (line/aux) • Input channels add analog audio to the digital audio network MXWANI8 • Front-panel gain and mute controls MXWANI4 • Headphone jack for monitoring and troubleshooting • Monitor LEDs display channel status and output levels...
  • Page 4: Audio Network Interface (Ani)

    Audio Network Interface (ANI) Front Panel ① ② ④ ⑤ ④ ⑤ ⑩ ⑪ push to solo | hold to mute ③ ⑥ ⑦ ③ ⑥ ⑧ ⑨ ⑫ ⑬ ① Input Channels ⑨ Output Attenuation Control Adds analog line- or aux-level signals to the digital network. When the Use the up/down buttons to attenuate the channel output from 0 dB (no device is associated to an MXW Group, inputs are automatically routed attenuation) to -24 dB in 1 dB increments, and from -24 to -78 in 3 dB...
  • Page 5: Back Panel

    IPOD or MP3 player, only use pins 1 (signal) and 3 (ground) of • Uplink Mode: only transports control data. This the block connector. See Specifications sections for wiring diagrams. mode blocks network audio and data for Shure Web ⑥ Reset Button Discovery Application, Dante Controller and Dante Virtual Soundcard.
  • Page 6: Operating System Requirements

    1. Install the Shure Web Device Discovery application. Download the Shure Web Device Discovery Application from www. shure.com or from the USB stick supplied with the MXW Access Point Transceiver. (The required Bonjour device discovery tool is bundled with the application and will install automatically.) 2.
  • Page 7: Inputs/Outputs Tab

    - Uplink Mode: Only control data default settings. Displays output audio levels prior to the digital-to-analog converter. is transported. Multicast traffic for Dante digital audio and the Shure ⑤ Register This Product Link ⑦ Attenuation Web Device Discovery application is Click to register the device restricted.
  • Page 8: Dante Controller

    MXW control software. The format for Shure device’s firmware is MAJOR.MINOR.PATCH. (Ex. 1.6.2 where 1 is the Major firmware level, 6 is the Minor firmware level, and 2 is the Patch firmware level.) At minimum, devices that operate on the same subnet should have identical MAJOR and MINOR release numbers.
  • Page 9: Analog Connections

    44 mm x 483 mm x 366 mm (1.7 in. x 19.0 in. x 14.4 in.), H x W x D AD/DA Converter Weight 24-bit, 48 kHz MXWANI4 3.1 kg (6.9 lbs) Latency MXWANI8 Estimated Nominal, ±0.1 ms 3.2 kg (7.1 lbs) Housing Analog-to-Dante 0.21 ms Steel; Extruded aluminum Dante-to-Analog 0.24 ms...
  • Page 10: Important Product Information

    CE marking. EMC conformance to Environment E2: Commercial and Light Industrial. The CE Declaration of Conformity can be obtained from Shure Incorporated Testing is based on the use of supplied and recommended cable types. or any of its European representatives. For contact information please visit The use of other than shielded (screened) cable types may degrade EMC www.shure.com...
  • Page 12 Europe, Middle East, Africa: PT. GOSHEN SWARA INDONESIA Kompleks Harco Mangga Dua Blok L No. 35 Jakarta Pusat I.16.GSI31.00501.0211...
