{ yyyyyyyyyyyyyyyyyyyyyyyyyyyyyyy }
>
Get Device ID
Command String:
< GET DEVICE_ID >
ANI22 Response:
< REP DEVICE_ID
{ yyyyyyyyyyyyyyyyyyyyyyyyyyyyyyy }
>
Get Firmware Version
Command String:
< GET FW_VER >
ANI22 Response:
< REP FW_VER { yyyyyyyyyyyyyyyyyy } >
Get Preset
Command String:
< GET PRESET >
ANI22 Response:
< REP PRESET nn >
Set Preset
Command String:
< SET PRESET nn >
ANI22 Response:
< REP PRESET nn >
Get Preset Name
Command String:
< GET PRESET1 >
< GET PRESET2 >
< GET PRESET3 >
etc
ANI22 Response:
< REP PRESET1
{yyyyyyyyyyyyyyyyyyyyyyyyy} >
is 31 characters of the user name. The
ANI22 always responds with a 31 character
name.
The Device ID command does not contain
the x channel character, as it is for the
entire ANI22.
Where
yyyyyyyyyyyyyyyyyyyyyyyyyyyyyyy
is 31 characters of the device ID. The ANI22
always responds with a 31 character device
ID.
Where yyyyyyyyyyyyyyyyyy is 18
characters. The ANI22 always responds with
18 characters.
Where nn is the preset number 01-10.
Where nn is the preset number 1-10.
(Leading zero is optional when using the
SET command).
Where nn is the preset number 01-10.
Send one of these commands to the ANI22
Where yyyyyyyyyyyyyyyyyyyyyyyyy is
25 characters of the device ID. The ANI22
always responds with a 25 character device
ID
