Most parameters will send a REPORT command when they change. Thus, it is not
necessary to constantly query parameters. The ANI22 will send a REPORT command when
any of these parameters change.
The character "x" in all of the following strings represents the channel of the ANI22 and
can be ASCII numbers 0 through 4 as in the following table
00 All channels
01, 02 Analog Inputs
03, 04 Analog Outputs
Command Strings (Common)
Get All
Command String:
< GET xx ALL >
ANI22 Response:
< REP ... >
Get Model Number
Command String:
< GET MODEL >
ANI22 Response:
< REP MODEL
{ yyyyyyyyyyyyyyyyyyyyyyyyyyyyyyyy }
>
Get Serial Number
Command String:
< GET SERIAL_NUM >
ANI22 Response:
< REP SERIAL_NUM
{ yyyyyyyyyyyyyyyyyyyyyyyyyyyyyyyy }
>
Get Channel Name
Command String:
< GET xx CHAN_NAME
ANI22 Response:
< REP xx CHAN_NAME
Where xx is ASCII channel number: 00
through 04. Use this command on first
power on to update the status of all
parameters.
The ANI22 responds with individual Report
strings for all parameters.
Where
yyyyyyyyyyyyyyyyyyyyyyyyyyyyyyyy
is 32 characters of the model number. The
ANI22 always responds with a 32 character
model number.
Where
yyyyyyyyyyyyyyyyyyyyyyyyyyyyyyyy
is 32 characters of the serial number. The
ANI22 always responds with a 32 character
serial number.
Where xx is ASCII channel number: 00
through 04.
Where
yyyyyyyyyyyyyyyyyyyyyyyyyyyyyyy
