< GET xx PEQ yy >
ANI22 Response:
< REP xx PEQ yy ON >
< REP xx PEQ yy OFF >
Set PEQ Filter Enable
Command String:
< SET xx PEQ yy ON >
< SET xx PEQ yy OFF >
ANI22 Response:
< REP xx PEQ yy ON >
< REP xx PEQ yy OFF >
Get Audio Summing Mode
Command String:
< GET AUDIO_SUMMING_MODE >
ANI22 Response:
< REP AUDIO_SUMMING_MODE OFF >
< REP AUDIO_SUMMING_MODE 1+2 >
< REP AUDIO_SUMMING_MODE 3+4 >
< REP AUDIO_SUMMING_MODE 1+2/3+4
>
Set Audio Summing Mode
Command String:
< SET AUDIO_SUMMING_MODE OFF >
< SET AUDIO_SUMMING_MODE 1+2 >
< SET AUDIO_SUMMING_MODE 3+4 >
< SET AUDIO_SUMMING_MODE 1+2/3+4 >
ANI22 Response:
< REP AUDIO_SUMMING_MODE OFF >
< REP AUDIO_SUMMING_MODE 1+2 >
< REP AUDIO_SUMMING_MODE 3+4 >
< REP AUDIO_SUMMING_MODE 1+2/3+4
>
Get Mic Logic Switch Out
Command String:
< GET HW_GATING_LOGIC >
yy is the PEQ filter 01-04 within the block.
00 can be used for all blocks or all filters.
Send one of these commands to the ANI22.
Where xx is the PEQ block 01-04. Where
yy is the PEQ filter 01-04 within the block.
00 can be used for all blocks or all filters.
The ANI22 will respond with one of these
strings.
Send one of these commands to the ANI22.
The ANI22 will respond with one of these
strings.
