General Description
The ANIUSB-MATRIX Audio Network Interface provides connections for USB, Dante
analog audio sources. Collaborate and connect with all audio devices on a single network,
with support for wireless microphones, computers, mobile devices, video codecs, and
loudspeaker systems. Connect with a single network cable to receive audio and power
through Power over Ethernet (PoE). A browser-based web application controls audio and
network settings from any computer connected to the same network.
Safety Information
IMPORTANT SAFETY INSTRUCTIONS
1. READ these instructions.
2. KEEP these instructions.
3. HEED all warnings.
4. FOLLOW all instructions.
5. DO NOT use this apparatus near water.
6. CLEAN ONLY with dry cloth.
7. DO NOT block any ventilation openings. Allow sufficient distances for adequate
ventilation and install in accordance with the manufacturer's instructions.
8. DO NOT install near any heat sources such as open flames, radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat. Do not place any
open flame sources on the product.
9. DO NOT defeat the safety purpose of the polarized or grounding type plug. A
polarized plug has two blades with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wider blade or the third prong are
provided for your safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. PROTECT the power cord from being walked on or pinched, particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. ONLY USE attachments/accessories specified by the manufacturer.
12. USE only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or
sold with the apparatus. When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
9/12/17, 8)20 AM
, and
™
Page 1 of 39

Advertisement

loading

Related Manuals for Shure ANIUSB-Matrix

Summary of Contents for Shure ANIUSB-Matrix

  • Page 1 Audio Network Interface General Description General Description Safety Information Getting Started The ANIUSB-MATRIX Audio Network Interface provides connections for USB, Dante , and ™ Hardware and Installation analog audio sources. Collaborate and connect with all audio devices on a single network,...

  • Page 2: Getting Started

    Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM 13. UNPLUG this apparatus during lightning storms or when unused for long periods of time. 14. REFER all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is...
  • Page 3 Use Dante Controller software to connect with other Dante devices and pass audio Access additional configuration information Step 1: Connect to a Network 1. Use an Ethernet cable (CAT5e or higher) to connect the ANIUSB-MATRIX to a network switch. Note: The network switch must provide Power over Ethernet (PoE). Make sure to connect to a PoE port, since many switches do not supply power on all ports.
  • Page 4 1. Find the MXA310 in the list of Dante transmitters, and select the plus sign (+) to show all channels. 2. Find the ANIUSB-MATRIX in the list of Dante receivers, and select the plus sign (+) to show all channels.
  • Page 5 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM Example: Connecting Loudspeakers, Wireless Microphones, and a Computer http://pubs.shure.com/guide/ANIUSB-Matrix/en-US Page 5 of 39...

  • Page 6: Rear Panel

    Note: Some connections are established in the matrix mixer by default. Refer to the matrix mixer help topic in the web application for additional information. 4. In the ANIUSB-MATRIX web application, adjust input and output levels and perform a sound check. Refer to the help topics in the web application for additional information.
  • Page 7 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM output levels in the web application to avoid clipping. Analog Input/Output LED State Audio Signal Level less than -60 dBFS Green -60 dBFS to -18 dBFS Yellow -18 dBFS to -6...
  • Page 8 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM input and output audio channels. LED Indicators Power: Power over Ethernet (PoE) present Note: Note: Use a PoE injector if your network switch does not supply PoE. Network: Network connection active Network Audio: Dante audio present on the network Note: Error details are available in the event log in the web application.
  • Page 9 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM small tool to press the button. There are two hardware reset functions: Network reset (press Resets all Shure control and audio network IP settings to factory button for 4-8 defaults seconds) Full factory reset...
  • Page 10 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM Align the holes as shown for securing a single device in the single-unit mounting tray Align the holes as shown for securing up to three devices in the 19" rack tray.
  • Page 11 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM Installing Underneath a Table 1. Hold the tray in the desired location under a table 2. Use a pencil to mark the location of the mounting holes on the table.
  • Page 12 Loudspeakers, amplifiers, or recording devices connect to the Devices analog line output. Dante-enabled Dante microphones, such as the Shure Microflex Advance ceiling Equipment and table arrays connect to the network switch and can be routed through the USB channel on the ANIUSB.
  • Page 13 The USB port connects the host computer to the entire room audio system, including microphones and loudspeakers. When the ANIUSB-MATRIX is connected for the first time, the computer recognizes it as a USB audio device. You may need to select it as the input/output (recording/playback) device to pass audio.
  • Page 14 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM the US Government National Institute of Standards and Technology (NIST) publication FIPS-197. Shure devices that support encryption require a passphrase to make a connection. Encryption is not supported with third-party devices. To activate encryption: 1.
  • Page 15 Example Scenario Hosting a meeting with a computer: Near-end audio from Dante microphones (Shure MXA 310) and an analog source (Shure wireless microphone system) are both routed to the USB input and sent to the far end. Far-end audio from the computer (USB input in the matrix mixer) can be sent to analog or Dante-enabled amplifiers and loudspeakers.
  • Page 16 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM Mute and Fader Groups Mute Groups Check the Mute group box to add the channel to a group. Muting any channel within the Mute group mutes all channels in the group.
  • Page 17 9/12/17, 8)20 AM Levels for analog and Dante channels are adjustable in the Input tab. To monitor input levels before they reach the ANIUSB-MATRIX, set the metering to pre- fader in the settings menu. When adjusting the faders, set metering to post-fader.
  • Page 18 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM Adjust frequency response for reinforcement systems Setting Filter Parameters Adjust filter settings by manipulating the icons in the frequency response graph, or by entering numeric values. Disable a filter using the check-box next to the filter.
  • Page 19 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM Copy, Paste, Import, and Export Equalizer Channel Settings These features make it simple to use effective equalizer settings from a previous installation, or simply accelerate configuration time. Copy and Paste Use to quickly apply the same PEQ setting across multiple channels.

  • Page 20: Using A Password

    Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM Hz to pinpoint the resonant frequency 3. Reduce the gain at the identified frequency (start between -3 and -6 dB) to minimize the unwanted room sound Custom Presets Use presets to quickly save and recall settings. Up to 10 presets can be stored on each device to match various seating arrangements.
  • Page 21 Shure Device Applications This device can connect with up to two Dante devices. The Shure MXA310, ANI22, ANIUSB-MATRIX and ANI4IN support multicast transmission. This means that flows can transmit to multiple devices -- as many as the network can support. If using unicast flows, each of these devices can connect with up to two Dante receiver devices.
  • Page 22 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM The character “x” in all of the following strings represents the channel of the ANIUSB and can be ASCII numbers 0 through 4 as in the following table All channels...
  • Page 23 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM ANIUSB Response: Where < REP xx CHAN_NAME yyyyyyyyyyyyyyyyyyyyyyyyyyyyyyy is 31 characters of the user name. The { yyyyyyyyyyyyyyyyyyyyyyyyyyyyyyy } ANIUSB always responds with a 31 > character name. Get Device ID...
  • Page 24 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM {yyyyyyyyyyyyyyyyyyyyyyyyy} > always responds with a 25 character device < REP PRESET2 {yyyyyyyyyyyyyyyyyyyyyyyyy} > < REP PRESET3 {yyyyyyyyyyyyyyyyyyyyyyyyy} > Get Audio Gain Command String: Where xx is ASCII channel number: 00 <...
  • Page 25 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM < REP xx AUDIO_IN_LVL_SWITCH AUX_LVL > Set Analog Input Gain Switch Command String: Where xx is ASCII channel number: 00 or < SET xx AUDIO_IN_LVL_SWITCH 05. Send one of these commands to the LINE_LVL >...
  • Page 26 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM Command String: < GET DEVICE_AUDIO_MUTE > ANIUSB Response: The ANIUSB will respond with one of these < REP DEVICE_AUDIO_MUTE ON > strings. < REP DEVICE_AUDIO_MUTE OFF > Set Device Audio Mute...
  • Page 27 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM MIC_LVL > Flash Lights on ANIUSB Command String: Send one of these commands to the < SET FLASH ON > ANIUSB. The flash automatically turns off after 30 seconds. < SET FLASH OFF >...
  • Page 28 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM ANIUSB Response: < REP LED_BRIGHTNESS n > Get Audio Clip Indicator Command String: Where xx is ASCII channel number: 00 < GET xx AUDIO_OUT_CLIP_INDICATOR through 10. > ANIUSB Response: The ANIUSB will respond with one of these <...
  • Page 29 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM Get Encryption Status Command String: < GET xx ENCRYPTION_CH > ANIUSB Response: The ANIUSB will respond with one of these < REP xx ENCRYPTION_CH ON > strings. < REP xx ENCRYPTION_CH OFF >...
  • Page 30 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM ANIUSB Response: The ANIUSB will respond with one of these < REP INPUT_METER_MODE PRE_FADER > strings. < REP INPUT_METER_MODE POST_FADER > Set Input Meter Display Mode Command String: Send one of these commands to the <...
  • Page 31 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM < REP USB_CONNECT OFF > < REP USB_CONNECT ERROR > Get Matrix Mixer Routing Command String: Where xx is input channel numbers 00-06. < GET xx MATRIX_MXR_ROUTE yy > Where yy is output channel numbers 00 or 07-10.
  • Page 32 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM ANIUSB Response: Where zzzz takes on the ASCII values of < REP xx MATRIX_MXR_GAIN yy zzzz 0000 to 1400. zzzz is in steps of one- > tenth of a dB.

  • Page 33: Event Log

    The Export feature creates a CSV (comma separated values) document to save and sort the log data. Refer to the log file for details when troubleshooting or consulting with Shure Systems Support. To view the event log: 1.

  • Page 34: Information To The User

    The use of other than shielded (screened) cable types may degrade EMC performance. Changes or modifications not expressly approved by Shure Incorporated could void your authority to operate this equipment. Industry Canada ICES-003 Compliance Label: CAN ICES-3 (B)/NMB-3(B) Authorized under the verification provision of FCC Part 15B.

  • Page 35: Specifications

    This product meets the Essential Requirements of all relevant European directives and is eligible for CE marking. The CE Declaration of Conformity can be obtained from Shure Incorporated or any of its European representatives. For contact information please visit www.shure.com...
  • Page 36 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM −29°C (-20°F) to 74°C (165°F) Thermal Power Dissipation Maximum 6.8W (23.0BTU/hr) typical 6.0W (20.8BTU/hr) Audio Frequency Response +1, -1.5 dB 20 to 20,000 Hz Dante Digital Audio Sampling Rate 48 kHz...
  • Page 37 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM Total Harmonic Distortion @ 1 kHz, 0 dBV Input, 0 dB analog gain <0.05% Common Mode Rejection Ratio 150Ω balanced source @ 1 kHz >70 dB Impedance 10.6 kΩ Input Clipping Level...
  • Page 38 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM 19" rack tray CRT1 http://pubs.shure.com/guide/ANIUSB-Matrix/en-US Page 38 of 39...
  • Page 39 Shure Publications | User Guides | ANIUSB-Matrix 9/12/17, 8)20 AM http://pubs.shure.com/guide/ANIUSB-Matrix/en-US Page 39 of 39...
