Configuring the SpectraLink 8000
SVP Server

Connecting to the SVP Server

PN: 1725-36032-001_G.doc
During initial setup of the SVP Server the IP address is established
and the maximum number of active calls per AP is set. Optionally,
you may enter a hostname and a location for software updates via
TFTP.
The initial connection to the SVP Server must be made via a serial
connection to establish the SVP Server's IP address. After the IP
address is established, connection to the SVP Server may be done via
the network using Telnet. It is recommended that the basic setup
actions occur while the serial connection is made.
Connect via the serial port
1. Using a DB-9 female, null-modem cable, connect the SVP Server to
the serial port of a terminal or PC.
2. Run a terminal emulation program (such as HyperTerminal™) or
use a VT-100 terminal with the following configuration:
Bits per second: 9600
Data bits: 8
Parity: None
Stop bits: 1
Flow control: None
3. Press Enter to display the SVP Server login screen.
4. Enter the default login:
are case sensitive.
5. The
Netlink SVP-II System
and default password:
admin
menu will display.
3
. These
admin
19
