11. SPECIFICATION

Operating voltage:
Power supply:
Current drain:
Dropout voltage:
Max. receiver and
servo current:
Servo signal resolution:
Signal repeat rate:
(frame rate)
Screen:
Servo sockets:
Temperature range:
Weight:
SensorSwitch:
EMV approval:
CE approval:
WEEE Reg. No.:
This battery backer fulfils the EMV protective requirements, EN
55014-1:2006 with certificate dated 10 February 2009. EMC approval
2004/108/EG.
The unit must not be connected to a mains PSU!
The PowerBox Cockpit, Competition and Professional is intended exclusi-
vely for use in modelling applications. It is prohibited to use it for any purpo-
se other than in radio-controlled models.
26
4.0 Volt to 9.0 Volt
2 x two-cell LiPo/LiIon battery, 7.4 Volt
2 x five-cell NiCd / NiMH batteries,
2 x two-cell LiFePo batteries (A123)
switched on - approx. 125 mA
switched off - approx. 33 µA
approx. 0.25 V
2 x 10 A (stabilised) according to cooling
Peak 2 x 20 A
0.5 µs
9 ms, 12 ms, 15 ms, 18 ms, 21 ms
OLED 128 x 64 pixels, graphic
Professional: 12 sockets, 8 channels
Competition: 18 sockets, 12 channels
Cockpit: 21 sockets, 11 channels
-30°C to +75°C
115 g
15 g
EN 55014-1:2006
2004/108/EG
DE 639 766 11
