PowerBox Systems cockpit Instruction Manual page 16

Mode 3:
Extend undercarriage:
Open nosewheel doors
Open main wheel doors
doors
Retract undercarriage:
Open nosewheel doors
Open main wheel doors
doors
Move the cursor to the appropriate mode, and press the SET button to con-
firm your choice. Select OK to move on to the next screen display:
Connect your retract system valve to output 4. One of the following will now
occur, depending on the way your valve is programmed:
Valve is triggered, and the undercarriage retracts. Press button II on your
SensorSwitch, and hold it pressed in until the undercarriage extends again.
Valve is not triggered, and the undercarriage remains in the extended state.
Press the SET button twice to move to the next screen display:
16
extend nosewheel
extend main undercarriage
retract nosewheel
retract main undercarriage
PowerBox-Systems − World Leaders in RC Power Supply Systems
close nosewheel doors
close main wheel
close nosewheel doors
close main wheel
