PowerBox Systems cockpit Instruction Manual page 23

8. TELEMETRY
The PowerBox Cockpit, Competition and Professional makes battery data
available as telemetry information which can be exploited by various makes
of radio control system. The unit supports the following makes of equip-
ment, and other systems will gradually be introduced as updates become
available:
- Jeti
Connect the PowerBox telemetry output to the receiver's EXT input using a
standard commercial Uni patch-lead. The voltage and residual capacity data
are now available at the transmitter.
- Futaba
Connect the PowerBox telemetry output to the receiver's sensor input using
the Teleconverter (Order No. 5600). The voltage and residual capacity of
both batteries are now available at the transmitter.
- Multiplex MSB
Connect the PowerBox telemetry output to the receiver's sensor input using
a standard commercial Uni patch-lead. The voltage and residual capacity of
both batteries are now available at the transmitter.
- Spektrum
Connect the four-pin Spektrum Telemetry output to the TM1000, and at the
same time bind the TM1000 and the connected satellites to the transmitter.
Activate the PowerBox Telemetry display at your transmitter. The voltage
and residual capacity of both batteries are now available at the transmitter.
The matching X-Bus lead for this can be obtained in various lengths from
Horizon Hobby:
SPMA9579
SPMA9580
SPMA9581
- HoTT
Connect the backer's telemetry output to the receiver's Sensor input using
a standard commercial Uni patch-lead. Select the "Electric Air Module" in
your transmitter's telemetry menu. The voltage of both batteries, and the
residual capacity of the weaker battery, can now be viewed on the trans-
mitter's screen.
www.powerbox-systems.com
X-Bus extension 150 mm
X-Bus extension 300 mm
X-Bus extension 600 mm
