Chapter 1- Hardware Description
1-32
3
Use the metal ejector levers to pull the
the Backplane.
4
Carefully slide the
5 On the Module to be installed, move the ejector lever to the
CNTL
fully open position.
6
Slide in the replacement
7
Push the
CNTL
properly seated in its slot.
8
Ensure that the metal ejector levers are fully retracted into their
housings.
9
Tighten the captive screws on the front panel of the RMX 2000 that
secure the Functional
10 Turn ON the RMX 2000.
For more information on the Card Configuration Modes after reset, see "MPM/
MPM+ and MPMx Configuration Modes" on page 1-22.
