RTM ISDN 1500 LEDS

The following LEDs appear on the RTM ISDN:
Table 1-9 RTM ISDN 1500 LEDs
LED
Function Name
Name
PRI (1-4) LEDs LNK
1 Gb

Power Supply LEDs

The following items appear on the rear panel power supply:
Table 1-10 Power Supply LED's
Component LED ID
Power Statuses OK
Alarm
AC
Polycom RMX 1500 Hardware Guide
LED Color Indication
Green ON with an active network
connection, flickers with Packet
activity.
Amber ON when 1Gb connection is
online, flickers with Packet
activity.
LED Color Indication
Green OK.
Amber PS Fail - Problem with power
supply. This amber LED is driven
by internal circuitry and will
illuminate when a power rail has
failed.
Green When the power cable is plugged-
in, the AC LED becomes lit.
1-19
