8.4 Chases

8.4.1 Recording chases
DMX DC-192
38
DMX controller
1. Keep [Program] pressed for about two seconds or until the PROG indicator flashes on the
display. When the indicator flashes, the recording mode is active and you can release the
button.
2.
To select a chase press the corresponding [CHASE] button (1 to 12). The corresponding
LED lights up.
3. Use the scene bank UP / DOWN buttons to first select the desired scene bank and then
the scene to be recorded. You can see the scene bank in the display by looking at the
digits on the right outer side. You can also adjust the scene using the eight channel
faders, the joystick or [PAGE SELECT]. Use [PAGE SELECT] to switch between channels 1 to
8 and 9 to 16.
4.
Press [Midi/Rec] to record the chase step. When the chase step is recorded, all LEDs flash
three times.
5. Repeat steps 3 and 4 to record further steps.
