20 [MIDI In]
MIDI input socket.
21 [MIDI Out]
MIDI output socket.
22 [FOG MACHINE]
To connect a fog machine with analogue interface.
23 [DMX Out]
DMX output socket to connect a dimmer or other DMX-controlled devices.
24 [DC In]
Connection socket for the 9 V power supply unit.
25 [POWER]
Main switch to turn the device on and off.
Connections and controls
