Radar Transmitters
SITRANS LR560 (PROFIBUS PA)
Operating Instructions 10/2010
SITRANS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SITRANS LR560 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Siemens SITRANS LR560

Summary of Contents for Siemens SITRANS LR560

  • Page 1 Radar Transmitters SITRANS LR560 (PROFIBUS PA) Operating Instructions 10/2010 SITRANS...
  • Page 2 The user is responsible for all changes and repairs made to the device by the user or the user’s agent. • All new components are to be provided by Siemens Milltronics Process Instruments. • Restrict repair to faulty components only.

  • Page 3: Table Of Contents

    CE Electromagnetic Compatibility (EMC) Conformity ..............2 Industry Canada ............................2 The Manual ...............................3 Application Example ........................3 Technical Support ............................3 Abbreviations and Identifications .......................4 SITRANS LR560 Overview ....................6 Programming ............................6 Local Display Interface (LDI) ......................7 Versions ..............................7 Applications ..............................7 Approvals and Certificates ........................7 Specifications ........................
  • Page 4 Device Address ............................37 Level application example ........................38 Operating via SIMATIC PDM ..................39 Functions in SIMATIC PDM ........................39 SIMATIC PDM Version .........................39 Electronic Device Description (EDD) ..................39 Configuring a new device ......................40 Set Address ...........................40 Quick Start Wizard via SIMATIC PDM .....................40 Quick Start .............................41 Changing parameter settings using SIMATIC PDM ..............44 Parameters accessed via pull-down menus ................44...
  • Page 5 LCD Contrast........................88 Remaining Device Lifetime ................... 88 Remaining Sensor Lifetime ................... 91 Service Schedule ......................94 Calibration Schedule ...................... 97 Communication........................100 Device Address ......................100 PROFIBUS Ident Number ................... 101 Security............................. 101 Remote Access......................101 Local Access ......................... 101 Language..........................
  • Page 6 Cyclic Data ..........................131 Status Byte ............................132 Condensed Status ........................132 Status Byte ..........................134 Diagnostics ............................135 Diagnosis reply (available cyclically) ..................135 Diagnosis Object (available cyclically or acyclically) ............136 Acyclic Extended Diagnostics (General Fault Codes) ............138 Acyclic Data ............................141 Appendix G: Firmware Revision History ..............142 Glossary ..........................

  • Page 7: Safety Notes

    FCC Conformity US Installations only: Federal Communications Commission (FCC) rules WARNING: Changes or modifications not expressly approved by Siemens Milltronics could void the user’s authority to operate the equipment. Notes: • This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 8: Ce Electromagnetic Compatibility (Emc) Conformity

    On the other hand, level probing devices found to interfere with primary licensing operations will be required to be removed at the user’s expense. Page 2 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 9: The Manual

    SITRANS LR560. • This manual applies to the SITRANS LR560 (PROFIBUS PA) only. This manual will help you set up your SITRANS LR560 for optimum performance. We always welcome suggestions and comments about manual content, design, and accessibility.

  • Page 10: Abbreviations And Identifications

    For on-line technical support go to: www.siemens.com/automation/support-request • Enter the device name (SITRANS LR560) or order number, then click on Search, and select the appropriate product type. Click on Next. • You will be prompted to enter a keyword describing your issue. Then either browse the relevant documentation, or click on Next to email a detailed description of your issue to Siemens Technical Support staff.
  • Page 11 Short Units Long Form Description form (cont’ d SELV Safety extra low voltage Secondary Value equivalent value Transducer Block Time Varying Threshold sensitivity threshold Input voltage Output voltage 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 5...

  • Page 12: Sitrans Lr560 Overview

    PROFIBUS Class I and Class II master. Programming SITRANS LR560 is very easy to install and configure via an optional graphical local display interface. You can modify the built-in parameters either locally via the push...

  • Page 13: Local Display Interface (Ldi)

    100 m range, 200 °C maximum process temperature Applications • solids bulk storage vessels • cement powder, plastic powder/pellets, grain, flour, coal, and other applications Approvals and Certificates SITRANS LR560 is available with General Purpose or Hazardous approvals. Application Approval Rating Valid for: Wiring Type Non- General N.

  • Page 14: Specifications

    Specifications Note: Siemens Milltronics makes every attempt to ensure the accuracy of these specifications but reserves the right to change them at any time. Power Bus powered 9 to 32 V DC, per IEC 61158-2 (PROFIBUS PA) Current consumed 13.5 mA...

  • Page 15: Interface

    Interface Communication • PROFIBUS PA 3.01 Configuration • remote Siemens SIMATIC PDM or FDT such as PACTWARE • local Siemens infrared handheld programmer or local control buttons Optional removable graphic LCD, with bar graph representing level local display interface (LDI)

  • Page 16: Environmental

    Maximum and minimum temperatures are dependent on the process connection, antenna and O-ring materials. Use of the Easy Aimer limits maximum temperature. Non-Sparking/Energy Limited wiring (Europe) and Dust Ignition Proof wiring (Europe/International) on page 25 for more details. Page 10 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 17: Programmer (Infrared Keypad)

    • To estimate the lifetime expectancy, check the nameplate on the back for the serial number. The first six numbers show the production date (mmddyy), for example, serial number 032608101V. Siemens Milltronics Infrared IS (Intrinsically Safe) Hand Programmer for hazardous and all other locations (battery is non-replaceable) • approval FM/CSA Class I, II, III, Div.

  • Page 18: Dimensions

    Dimensions SITRANS LR560 with stainless steel Universal Flat-faced Flange Universal Slotted Flange Note: Refer to on page 16 for bolt hole patterns and dimensions. lid lock device label cable gland 176 mm grounding (6.93") purge inlet pressure/ temperature related information...
  • Page 19 23.3 mm (0.92" sensor reference point 110 mm (4.33") 200 mm (7.87") Shipped with product, packed in a separate bag. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 13...
  • Page 20 SITRANS LR560 with 4" and 6" Aimer Flange Universal Slotted Flange Note: Refer to on page 16 for bolt hole patterns and dimensions. lid lock cable gland device label grounding 166.1 mm (6.54") purge inlet pressure/ temperature related information process connection: 4": 53.2 mm (2.09")
  • Page 21 Date of Pressure Test (Year/Month/Day) PROCESS SERIES 25785 Pressure Tag Family Series WETTED NON-METALLIC Sensor Lens Material WETTED METALLICS 304L Process Connection Material(s) WETTED SEALS FKM / VQM Seal Material(s) 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 15...
  • Page 22 9.53" 9.45" 0.45" 150 mm (285 mm) (9.65 mm) (242 mm) (240 mm) (11.5 mm) Universal flange mates with EN 1092-1 (PN16)/ASME B16.5 (150 lb)/JIS 2220 (10K) bolt hole pattern. Page 16 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 23: Installation

    • Installation shall be performed only by qualified personnel and in accordance with local governing regulations. • SITRANS LR560 is to be used only in the manner outlined in this manual, otherwise protection provided by the device may be impaired.

  • Page 24: Mounting Location

    Provide an environment suitable for the ambient temperature rating. process temperature: –40 to +100 °C (–40 to +212 °F) or –40 to +200 °C (–40 to +392 °F) depending on the version Page 18 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 25: Aimer Adjustment

    The LR560 display can be protected by an optional sunshield if the instrument will be mounted in direct sunlight. Aimer Adjustment Note: Aiming will assist in measuring material in the cone. 3" flange 4 and 6" flange 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 19...

  • Page 26: Air Purging System

    Markings on the flange indicate minimum and maximum rotation (see Display on page 22). Direct SITRANS LR560 so the antenna is pointed at an angle perpendicular to the material surface, if possible. When the desired position is reached, re-tighten the locking ring using the C spanner, and tighten set screws.

  • Page 27: Purge Connection

    The air purge system can clean both dust and moisture off the lens. • It can be used for periodic cleaning. angled holes direct air flow Air pressure in vessel can affect purge operation. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 21...

  • Page 28: Removable Display

    Connecting SITRANS LR560 apart (see on page 23 for instructions). Copy • It can also be used to transfer parameters from one device to another. (See Parameters to Display on page 64.) Page 22 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 29: Wiring

    70 mm (2.75") from the end of the 3) ¼ turn PROFIBUS PA cable, and thread the wires through the gland If cable is routed through conduit, use only approved suitable-size hubs for waterproof applications. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 23...

  • Page 30: Basic Plc Configuration With Profibus Pa

    Connect the wires to the terminals as shown (SITRANS LR560 PA is not polarity- 1) 2) sensitive.) cable cable gland shield (or NPT cable entry) instrument shield connection Ground the instrument according to local regulations. Tighten the gland to form a good seal.

  • Page 31: Wiring Setups For Hazardous Area Installations

    The ATEX certificate listed on the nameplate can be downloaded from the product page of our website at: www.siemens.com/LR560. Go to Support > Approvals/Certificates. The IECEx certificate listed on the nameplate can be viewed on the IECEx website. Go to: http://iecex.iec.ch and click on Ex Equipment Certificates of Conformity then enter the...

  • Page 32: Instructions Specific To Hazardous Area Installations

    2. Non-incendive and Dust Ignition Proof wiring (US/Canada) Device label (FM/CSA) FM/CSA Class 1, Div 2 connection drawing number A5E02795836 can be downloaded from the product page of our website at: www.siemens.com/LR560 under Support. Temperature De-Rating • For power demands see on page 123.
  • Page 33 ‘e’ or flameproof ‘d’ . • The supply to the equipment shall be rated for a prospective short-circuit current of not more than 10 kA and shall protected by a suitably-rated fuse. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 27...

  • Page 34: Local Operation

    Local Operation SITRANS LR560 carries out its level measurement tasks according to settings made via parameters. The settings can be modified locally via the Local Display Interface (LDI) which consists of an LCD display with push buttons. You can use either the push buttons or an infrared handheld programmer to make changes.

  • Page 35: The Lcd Display

    Press UP or DOWN arrow to switch. Key functions in Measurement In response to a key press request. For details, see mode on page 30. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 29...

  • Page 36: Handheld Programmer

    PROGRAM mode. UP or DOWN arrow Identifies which AIFB is the source of the displayed toggles between AIFB 1 and value. AIFB 2. See Confidence (2.4.7.1.) on page 74. Page 30 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 37: Programming Sitrans Lr560

    • While the device is in PROGRAM mode the output remains active and continues to respond to changes in the device. • SITRANS LR560 automatically returns to Measurement mode after a period of inactivity in PROGRAM mode (between 15 seconds and 10 minutes, depending on the menu level).
  • Page 38 Edit mode. The current selection is highlighted. Scroll to a new selection. Press RIGHT arrow to accept it The LCD returns to parameter view and displays the new selection. Page 32 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 39 Erases the display. editing Decimal Numeric Enters a decimal point. point editing Plus or Numeric Changes the sign of the entered value. minus sign editing Numeric Numeral Enters the corresponding character. editing 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 33...

  • Page 40: Quick Start Wizard Via The Ldi Push Buttons

    • Do not use the Quick Start wizard to modify individual parameters: see instead Parameter Reference on page 62. (Perform customization only after the Quick Start has been completed.) • Default settings in the parameter tables are indicated with an asterisk (*). Page 34 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 41 0.1 m/min (0.32 ft/min) 10 s 1.0 m/min (3.28 ft/min) FAST 10.0 m/min (32.8 ft/min) Use a setting just faster than the maximum vessel filling or vessel emptying rate (whichever is greater). 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 35...
  • Page 42 Quick Start is successfully completed.) To transfer Quick Start values to the device and return to Program menu, press DOWN arrow (Finish). Then press LEFT arrow to return to Measurement mode. Page 36 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 43: Requesting An Echo Profile

    Edit mode. If required, key in a new value and press RIGHT arrow to accept it. The LCD displays the new value. Press Mode to return to Measurement mode. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 37...

  • Page 44: Level Application Example

    Resets Fill Rate/ Empty Rate to 0.1 m/minute. Units Sensor measurement units. Operation LEVEL (1) Material level referenced from Low Cal. Point. Low Calibration Point 15.5 Process empty level. High Calibration Point Process full level. Page 38 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 45: Operating Via Simatic Pdm

    Operating via SIMATIC PDM SIMATIC PDM is a software tool used to commission and maintain SITRANS LR560 and other process devices. Please consult the operating instructions or online help for details on using SIMATIC PDM. (You can find more information at www.siemens.com/simatic-pdm.)

  • Page 46: Configuring A New Device

    • Application Guides for setting up PROFIBUS PA devices with SIMATIC PDM can be downloaded from the product page of our website at: www.siemens.com/LR560. To install a Check that you have the most recent EDD, and if necessary update it (see new EDD above).

  • Page 47: Quick Start

    • For a vessel with obstructions see on page 48. Launch SIMATIC PDM, open the menu Device – Wizard - Quick Start, and follow steps 1 to 4. Quick Start 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 41...
  • Page 48 • Selecting CONCRETE changes the setting for Position Detect (2.4.5.2.) to Rising Edge and for Algorithm (2.4.5.1.) to ALF. Select the application type: steel or concrete vessel. [This changes the setting for Position Detect (2.4.5.2.) to Rising Edge.] Click on NEXT. Page 42 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 49 Check parameter settings, and click on BACK to return and revise values, FINISH to save settings offline, or FINISH AND DOWNLOAD to save settings offline and transfer them to the device. The message Quick Start was successful will appear. Click on OK. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 43...

  • Page 50: Changing Parameter Settings Using Simatic Pdm

    Many parameters are accessed via the 5-level menu in PDM. See pull-down menus on page 44 for the others. Launch SIMATIC PDM, connect to SITRANS LR560, and upload data from the device. Adjust parameter values in the parameter value field then press Enter. The status fields read Changed.
  • Page 51 46 (via tab) View Saved Echo Profiles • on page 46 TVT Shaper • on page 47 Auto False Echo Suppression • on page 48 Echo Setup • on page 50 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 45...
  • Page 52 Click on the tab View Saved Echo Profiles to view the stored profiles View Saved Echo Profiles To view a saved profile, click on the tab View Saved Echo Profiles. Page 46 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 53 Change the position of the cursor on the TVT using the Point+ and Point– buttons: raise and lower the TVT using Offset+ and Offset–. • Alternatively, enter values for Point and Offset directly into the dialog boxes. • Click on Transfer to Device. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 47...
  • Page 54 Determine Auto False Echo Suppression Range. Measure the actual distance from the sensor reference point to the material surface using a rope or tape measure. Subtract 0.5 m (20") from this distance, and use the resulting value. Page 48 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 55 Before Auto False Echo Suppression false echo default TVT material level Hover Level echo marker After Auto False Echo Suppression Auto False Echo Suppression Range material level learned default echo marker false echo 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 49...
  • Page 56 Maintenance You can set schedules for: • maintenance of the device based on its projected lifetime • maintenance of the sensor based on its projected lifetime • service • calibration Page 50 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 57 AIFB (simulation, mode and status) parameters. (See on page 127 for detailed explanations.) You can also simulate input and output values, accessed via pull-down menus: see Simulation on page 52. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 51...
  • Page 58 See below, to set the output mode. After simulation is complete, disable simulation and click on Transfer. Status Byte on page 132 for more information on status and quality. Page 52 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 59 Open the menu Device – Simulation, select function block 1 or 2, and click on the tab Simulation (Output). Select Out of Service Mode and click on Transfer. After maintenance is complete, return to Simulate Output, reselect AUTO mode, and click on Transfer. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 53...
  • Page 60 Locking is enabled, the data can be viewed but not modified. To enable/disable Write Protection: 1) Open the menu Device – Write Locking and turn Write Protection On or Off. 2) Click on Transfer. Page 54 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 61 1) Open the menu Device – Master Reset and click on Reset Address to ’126’ . 2) Click on OK: the address will be reset to 126, and if the address lock was on, it will be disabled. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 55...

  • Page 62: Diagnostics

    57. • Sensor Value and simulation setting • Electronics temperature • Measured Value (level, volume , and distance) together with quality and status. Not supported by LR560. Page 56 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 63 AIFB1 and AIFB2. trend line trend line Device Diagnostics Device Status Open the menu View - Device Diagnostics > Device Status to view Diagnostics, Device Status, Extended Diagnostics, and Maintenance 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 57...
  • Page 64 Update diagnostics Device Status Click on the Device Status tab to view peak sensor values, peak FB1 and FB2 values, and peak electronics temperatures. Page 58 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 65: Security

    Open a project, double-click on the device icon, and in the User window select Specialist. Open the menu Options – Settings and click on the Password tab. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 59...
  • Page 66 Enter a new password and re-enter it in the Confirmation window. Click on OK. Page 60 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 67: Operating Via Fdt (Field Device Tool)

    Click on Product Support then go to Product Information/Process Instrumentation/Software & Communications. The instrument EDD The SITRANS LR560 PROFIBUS PA EDD for SITRANS DTM can be downloaded from the product page of our website. Go to www.siemens.com/LR560 under Support and click on Software Downloads.

  • Page 68: Parameter Reference

    Quick Start Wizard via the LDI push buttons on page 34 • Quick Start Wizard via the handheld programmer on page 34 • Quick Start Wizard via SIMATIC PDM on page 40 • Page 62 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 69: Afes (Auto False Echo Suppression) Wizard

    If you have a vessel with known obstructions, we recommend using AFES to prevent false echo detection. This feature can also be used if SITRANS LR560 displays a false high level, or the reading is fluctuating between the correct level and a false high level.

  • Page 70: Copy Parameters To Display

    Edit. • Press DOWN arrow to select Start and RIGHT arrow to begin the transfer. SW UPLOAD is displayed during the transfer, then the device returns to Measurement mode. Page 64 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 71: Copy Firmware From Display

    SW DOWNLOAD is displayed at the beginning of the transfer. This is followed first by a blank screen (for approximately 2 minutes), then by a progress indicator, and then by the Siemens logo with the LOE icon. When the transfer is complete,the device returns to Measurement mode.

  • Page 72: Sensor

    Range: 15 to 65535 s. Default: 120 s Values 2.2.5. Manufacturing Date The date of manufacture of the SITRANS LR560 (YYYYMMDD). 2.3. Sensor 2.3.1. Unit Sensor measurement unit. Used in setting High/Low Calibration Point, and displayed on LCD and in PDM.
  • Page 73 When setting the High Calibration Point value, note that echoes are ignored within Near Range (2.4.1.) Dimensions The point on the sensor from which measurements are referenced (see on page 12 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 67...
  • Page 74 Use a setting just faster than the maximum filling or emptying rate (whichever is greater). Minimum Sensor Value 2.4.3. The distance from sensor reference point to target (see on page 70 for an illustration. Page 68 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 75: Signal Processing

    Fill Rate/Min Defines the maximum rate at which the reported sensor value is allowed to increase. Allows you to further adjust the SITRANS LR560 response to increases in the actual material level. Fill Rate is automatically updated whenever Response Rate (2.3.6.1.) is altered.
  • Page 76 (Default : 105 m for 100 m device, 45 m for 40 m device) • Open the menu View – Device Diagnostics > Device Status, and click on the Device Status tab. • Check Sensor Peak Values. Page 70 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 77 If the vessel bottom is being reported as the level instead of the actual material level (at low level conditions) we recommend setting Position Detect to Hybrid and using it in combination with CLEF Range (2.4.5.4.). 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 71...
  • Page 78 Range: 0 to 45 m (40 m device) 0 to 105 m (100 m device) Values Default: 0.0 m Position Detect (2.4.5.2.) Related parameters Far Range (2.4.2.) sensor reference point CLEF Range Low Calibration Point Range Page 72 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 79 Sampling down Specifies the number of consecutive echoes that must appear below the echo currently selected, before the measurement is accepted as valid. Range: 1 to 50 Values Default: 2 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 73...
  • Page 80 –20 to 99 Values (view only) Open the menu Device – Echo Profile Utilities and click on the tab Echo Profile. Echo Lock (2.4.6.1.) on page 118 for more detail. Page 74 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 81 When the device is located in the center of the vessel, the TVT hover level may be lowered to increase the confidence level of the largest echo. 2.4.8.4. Shaper Mode Enables/disables TVT shaper (2.4.9.). Options 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 75...
  • Page 82 2.4.9.5. Breakpoint 37-45 2.4.9.6. Breakpoint 46-54 2.4.9.7. Breakpoint 55-63 2.4.9.8. Breakpoint 64-72 2.4.9.9. Breakpoint 73-81 2.4.9.10. Breakpoint 82-90 2.4.9.11. Breakpoint 91-99 2.4.9.12. Breakpoint 100-108 2.4.9.13. Breakpoint 109-117 2.4.9.14. Breakpoint 118-120 Page 76 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 83: Aifb1

    Note: Ensure that Mode is returned to AUTO when simulation or mainte- nance are completed. Used to request an operating mode from the Analog Input Function Block. Allows you to put SITRANS LR560 into Manual mode (used in conjunction with Simulation) or Out-of-Service mode for maintenance purposes. Setting Description...
  • Page 84 Range: -999999 to 999999 Values Default: 100% 2.5.6.2. Lower Value Defines the operational lower range value of the output value in AIFB1 units. Range: -999999 to 999999 Values Default: 0% Page 78 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 85 Values Default: 0.20 Enter a value for the hysteresis here, to be used for all warnings and alarms. The units are the same as the Output scale, i.e. AIFB1 units. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 79...
  • Page 86 Substitute value. Value (2.5.9.2.) used as SUB VALUE output value. LAST VALUE Last value. (Store last valid output value). Options Use bad value. (Calculated output value is USE BAD VALUE incorrect). Page 80 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 87: Aifb2

    Range: 0 to 255 samples. Default: 0 (reset to 10 after a Quick Start has been completed) 0 = OFF Values greater = wider Recommended: 5 to 20 samples. Wider is not recommended. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 81...

  • Page 88: Diagnostics

    Calibration Schedule Reminder 1 (Maintenance Required) Calibration Schedule Reminder 2 (Maintenance Demanded) To clear a fault using the handheld programmer: • Enter the fault code number then press RIGHT arrow. Page 82 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 89: Trend

    Open the menu View – Process Variables and click on the tab Trend View. 3.4. Electronics Temperature 3.4.1. Minimum Value The minimum recorded internal electronics temperature of the SITRANS LR560. 3.4.2. Maximum Value The maximum recorded internal electronics temperature of the SITRANS LR560.

  • Page 90: Allocation

    Go to Maintenance & Diagnostics > Allocation Level. c) For each event, you can select either the Status or the Diagnosis line, then choose a Status or Diagnosis option from the associated pull-down menu. Page 84 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 91 Maintenance Required Maintenance Demanded Maintenance alarm Invalid process conditions Function check or simulation Condensed Status on page 132 for more detail. Condensed Mode Diagnosis on page 136 for more detail. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 85...

  • Page 92: Peak Values

    Note: Default settings in the parameter tables are indicated with an asterisk (*) unless explicitly stated. 4.1. Demo Mode Reduces the time between measurements and the accuracy for demonstration purposes. Page 86 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 93: Master Reset

    Press LEFT Arrow to exit. 4.3. Powered Hours Read only. Displays the number of hours the unit has been powered up since manufacture. To view via SIMATIC PDM, open the menu Device – Wear. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 87...

  • Page 94: Power-On Resets

    The maintenance warnings and alarms are communicated via the Status byte. This information can be integrated into any Asset Management system. For optimal use, we recommend that you use SIMATIC PCS7 Asset Management Software in conjunction with SIMATIC PDM. Page 88 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 95 4.7.2. Time in Operation Read only. The amount of time the device has been operating in years. 4.7.3. Remaining Lifetime Read only. Lifetime Expected (4.7.1.) less Time in Operation (4.7.2.). 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 89...
  • Page 96 Indicates which level of maintenance reminder has been acknowledged. In SIMATIC PDM, open the menu View – Device Diagnostics, select Device Status, click on the Maintenance tab, and check the Device Lifetime Status window. Page 90 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 97: Remaining Sensor Lifetime

    The device monitors the predicted lifetime of the sensor (the components exposed to the vessel environment). You can modify the expected sensor lifetime, set up schedules for maintenance reminders, and acknowledge them. To access these parameters via SIMATIC PDM: on page 92 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 91...
  • Page 98 • Via the handheld programmer, manually reset Time in Operation (4.8.2.) to zero. 4.8.3. Remaining Lifetime Read only. Lifetime Expected (4.8.1.) less Time in Operation (4.8.2.). Page 92 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 99 Indicates which level of maintenance reminder has been acknowledged. In SIMATIC PDM, open the menu View – Device Diagnostics, select Device Status, click on the Maintenance tab, and check the Sensor Lifetime Status window. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 93...

  • Page 100: Service Schedule

    After modifying values/units as required, click on Write to accept the change, and Read to view the effect of the change. • Click on Service Performed to restart the timer and clear any fault messages. Page 94 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 101 • Via the handheld programmer, manually reset Time since Last Service (4.9.2.) to zero. 4.9.3. Time until Next Service Read only. Service Interval (4.9.1.) less Time since Last Service (4.9.2.). 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 95...
  • Page 102 Indicates which level of maintenance reminder has been acknowledged. Open the menu View – Device Diagnostics, select Device Status, click on the Maintenance tab and check the Service Schedule Status window. Page 96 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 103: Calibration Schedule

    After modifying values/units as required, click on Write to accept the change, and Read to view the effect of the change. • Click on Calibration Performed to restart the timer and clear any fault messages. (continued on next page) 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 97...
  • Page 104 • Via the handheld programmer, manually reset Time since Last Calibration (4.10.2.) to zero. 4.10.3. Time until Next Calibration Read only. Calibration Interval (4.10.1.) less Time since Last Calibration (4.10.2.) Page 98 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 105 Indicates which level of maintenance reminder is active. In SIMATIC PDM, open the menu View – Device Diagnostics, select Device Status, click on the Maintenance tab, and check the Calibration Schedule Status window. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 99...

  • Page 106: Communication

    0 - 126. Default: 126 Values To reset Device Address via SIMATIC PDM: Set Address on page 40 To change Device Address via the handheld programmer: Device Address on page 37 for details. Page 100 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 107: Profibus Ident Number

    Selects the language to be used on the LCD. ENGLISH DEUTSCH FRANÇAIS Options ESPAÑOL CHINESE To access Language via SIMATIC PDM: Navigate to Level Meter > Setup > Local Display. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 101...
  • Page 108 Notes Page 102 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 109: Appendix A: Alphabetical Parameter List

    Enable (3.5. 1 .) Event Index (3.6.1.) Event Status (3.6.2.) Event Diagnosis (3.6.3.) Far Range (2.4.2.) Fault Reset (3.2.) Features enabled (3.5.3.) Features supported (3.5.2.) Fill Rate/Min (2.3.6.2.) Filter Time Constant (2.5.8.1.) 7ML19985LT01 SITRANS LR560(PROFIBUS PA) – OPERATING INSTRUCTIONS Page 103...
  • Page 110 Measured Values (2.7.) Menu timeout (2.2.4.) Message (2.1.3.) Min. Measured Value (3.7.1.) Minimum Output Value - AIFB1 (3.7.3.) Minimum Output Value - AIFB2 (3.7.5.) Minimum Sensor Value (2.4.3.) Minimum Value (3.4.1.) Page 104 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 111 Shaper Mode (2.4.8.4.) Signal Processing (2.4.) Static Revision No. (2.5.1.) Tag (2.1.1.) Temperature Unit (2.3.4.) Trend (3.3.) TVT setup (2.4.8.) TVT shaper (2.4.9.) Unit (2.3. 1 .) Value (2.5.9.2.) Write Protection (6.2.1.) 7ML19985LT01 SITRANS LR560(PROFIBUS PA) – OPERATING INSTRUCTIONS Page 105...

  • Page 112: Appendix B: Troubleshooting

    • Check the network to ensure the PCL is communicat- ing with the LR560. If you continue to experience problems, go to our website at: www.siemens.com/LR560, and check the FAQs for SITRANS LR560, or contact your Siemens Milltronics representative. Page 106 SITRANS LR560 (PROFIBUS PA) –...

  • Page 113: Device Status Icons

    • Simulation or substitute value • Communication is good; device is in simulation mode or works with substitute values. • Out of operation • Communication is good; device is out of action. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 107...

  • Page 114: General Fault Codes

    • If fault persists, contact your local Siemens representative. S: 2 Unable to collect profile because of Repair required. Contact your local a power condition that is outside the Siemens representative. operating range of the device. Page 108 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 115 (2.3.5.2.) are the same. • Ensure settings for High Calibra- tion Point and Low Calibration Point are different. S: 11 Internal temperature sensor failure. Repair required: contact your local Siemens representative. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 109...
  • Page 116 Internal device failure caused by an Repair required: contact your local External RAM memory error. Siemens representative. S: 28 Internal device failure caused by a Repair required: contact your local RAM memory error. Siemens representative. Page 110 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 117 Siemens representative. S:40 Transducer temperature too high. Relocate device and/or lower process temperature enough to cool device. Inspect for heat-related damage and contact your local Siemens representative if repair is required. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 111...

  • Page 118: Operation Troubleshooting

    Auto False Echo Suppression • Auto False Echo Suppres- • review (2.4.8. 1 .) sion may be incorrectly on page 118 applied • ensure Auto Suppression Range is set correctly Page 112 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 119 Range zone mum value depends on antenna type • multiple echoes pro- • raise SITRANS LR560 cessed • ensure Algorithm (2.4.5. 1 .) is set to tF (trueFirst echo) 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 113...

  • Page 120: Appendix C: Maintenance

    Appendix C: Maintenance SITRANS LR560 requires no maintenance or cleaning under normal operating conditions. Under severe operating conditions, the antenna may require periodic cleaning. If cleaning becomes necessary: • Note the antenna material and the process medium, and select a cleaning solution that will not react adversely with either.

  • Page 121: Appendix D: Technical Reference

    Electromagnetic waves are not attenuated by dust. SITRANS LR560 consists of an enclosed electronic circuit coupled to an antenna and process connection. The electronic circuit generates a radar signal (78 GHz) that is directed to the lens antenna.

  • Page 122: Echo Selection

    Hybrid Uses the Center algorithm for the top part of the vessel, and the CLEF algorithm for the part nearest the vessel bottom, according to the setting for CLEF range. Page 116 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 123 Example: CLEF enabled Vessel height: 1.5 m; CLEF range set to 0.5 m default TVT vessel bottom material echo echo selected echo marker 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 117...
  • Page 124 In radar applications, two measurement verification options are used: Lock Off SITRANS LR560 responds immediately to a new selected echo (within the restrictions set by the Maximum Fill / Empty Rate), but measurement reliability is affected. Material Agitator A new measurement outside the Echo Lock Window must meet the sampling criteria before the window will move to include it.
  • Page 125 = 45 m Example after Auto False Echo Suppression Auto False Echo Suppression Auto False Echo learned Suppression Range Range set to 20 m default TVT material echo echo false echo marker 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 119...

  • Page 126: Measurement Range

    Measurement Range Near Range (2.4.1.) Near Range programs SITRANS LR560 to ignore the zone in front of the antenna. The default blanking distance is 27.8 cm (0.91 ft) from the sensor reference point. Near Range allows you to increase the blanking value from its factory default. But Auto False Echo Suppression (2.4.8.1.) is generally recommended in preference to extending...

  • Page 127: Damping

    LOE Timer (2.3.3.) determines the length of time a Loss of Echo (LOE) condition will persist before a Fail-safe state is activated. The default is 100 seconds. Fail-safe Mode determines the level to be reported when the Fail-safe timer expires. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 121...

  • Page 128: Fail-Safe Behavior

    Navigate to the Level Meter > Setup > desired Analog Input (1 or 2). • Set Mode (2.5.9.1.) to Use substitute value. • Go to Value (2.5.9.2.) and enter the desired value. Page 122 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 129: Temperature Derating Curve

    –40 to +100 °C (–40 to +212 °F) or –40 to +200 °C (–40 to +392 °F) depending on the version Temperature De-Rating standard high temperature version version Process Temperature (°C) 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 123...

  • Page 130: Appendix E: Profibus Pa Profile Structure

    The output from the Analog Input Function Block supplies the measured value with associated status information to the PROFIBUS PA network via cyclic data transfer. Primary Value (PV), Secondary Value 1 (SV1), or Secondary Value 2 (SV2) Page 124 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 131: Description Of The Blocks

    A Sensor Offset (default 0) compensates for changes to the sensor reference point, if necessary. (continued on next page) PV output is provided for PROFIBUS Profile for Process Devices 3.01 compatibility. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 125...
  • Page 132 Sensor Offset (2.3.5.3.) is a constant offset (negative or positive) that can be added to sensor value to compensate if the sensor has been changed. Level Offset (default O) can compensate for specific vessel configurations. LR560 PA does not support Volume. Page 126 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 133 LCD as PLC) Output range: (continued on next page) Open the menu View – Device Diagnostics, select Device Status, and click on the tab Device Status to see peak temperature values. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 127...
  • Page 134 See Alarms and Warnings (2.5.7.) on page 79 for the specific parameters. The output value (OUT) is communicated via cyclic data transfer. Page 128 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 135: Appendix F: Communications Via Profibus Pa

    Appendix F: Communications via PROFIBUS PA SITRANS LR560 (PROFIBUS PA) is a Profile Version 3.01, Class B, PA device. It supports Class 1 Master for cyclic and acyclic data exchange, and Class 2 for acyclic services. The full range of SITRANS LR560 functions is available only over a PROFIBUS PA network.

  • Page 136: Profibus Address

    Defining the device as Profile-specific as opposed to Manufacturer-specific makes it possible to exchange the device for any other device of the same profile type without changing the GSD file. To set up SITRANS LR560 as a profile device see PROFIBUS Ident Number (5.2.) on page 101. Page 130 SITRANS LR560 (PROFIBUS PA) –...

  • Page 137: Configuring A Device

    40. Configuring PROFIBUS PA with an S7-300/ 400 PLC If SITRANS LR560 is not listed in the STEP 7 device catalog, you can download the GSD file from the Siemens Web site and import it into Step 7. Go to www.siemens.com/LR560 and click Downloads.

  • Page 138: Status Byte

    Status Codes for Good Quality on page 134..0x8E update event 0xA0 GOOD – initiate fail This fault is not generated by the product, but can be simu- ...0xA3 safe lated. Page 132 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 139 • In simulation mode the written status is buffered and appears in the value flow after 10 seconds. However the new written SIMULATE parameter with its status can be read before the 10 seconds have expired. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 133...

  • Page 140: Status Byte

    A parameter in the function block has been changed: status active 0x84 for 10 s 0x89 Active low warning. 0x8A Active high warning. 0x8D Active low alarm. 0x8E Active high alarm. Page 134 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 141: Diagnostics

    The same information is also available acyclically via the Diagnosis Object. Cyclic Diagnosis (6 bytes) Extended Cyclic Diagnosis (8 bytes) Diagnosis Object (last 4 bytes) Extended Mode Condensed Mode Diagnosis Diagnosis 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 135...

  • Page 142: Diagnosis Object (Available Cyclically Or Acyclically)

    1: More diagnosis information is available in DIAGNOSIS_EXTENSION R indicates the message remains active as long as the reason for the message exists. A indicates the message will automatically reset after 10 seconds Page 136 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 143 R indicates the message remains active as long as the reason for the message exists. A indicates the message will automatically reset after 10 seconds Values of the DIAGNOSIS bit: 0 = not set; 1 = set 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 137...

  • Page 144: Acyclic Extended Diagnostics (General Fault Codes)

    Replacement is recommended. limit according to the value set in Maintenance Required Limit. Sensor is nearing its lifetime Replacement is recommended. limit according to the value set in Maintenance Demanded Limit. Page 138 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 145 Scale) are not the same. Calibration interval as defined in Maintenance Required Limit Perform calibration. S: 17 has expired. Calibration interval as defined in Maintenance Demanded Limit Perform calibration. S: 18 has expired. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 139...
  • Page 146 Transducer temperature too Relocate device and/or lower high. process temperature enough to cool device. Inspect for heat- S:40 related damage and contact your local Siemens representative if repair is required. Page 140 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 147: Acyclic Data

    Acyclic Data SITRANS LR560 supports up to four simultaneous connections by a Class 2 Master (C2 connection). It supports one connection by a Class 1 Master (C1 connection). In order for a Class 1 Master to read parameters from an instrument, it needs to know the slot and absolute index of the parameter.

  • Page 148: Appendix G: Firmware Revision History

    Appendix G: Firmware Revision History Firmware Date Changes Rev. Rev. (DD/MM/YYYY) 1.00.00 1.00.00 26 May 2010 • Initial release. Page 142 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 149: Glossary

    Many conductive liquids/electrolytes exhibit dielectric properties; the relative dielectric constant of water is 80. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 143...
  • Page 150 Page 144 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 151 TVT (time varying threshold): a time-varying curve that determines the threshold level above which echoes are determined to be valid. waveguide antenna: a hollow, metallic tube that transmits a microwave signal to the product target. 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 145...
  • Page 152 Notes Page 146 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 153: Index

    80 Far Range see electronic device description 129 explanation 120 Device Address 100 fault codes device description acyclic diagnostics 136 see Electronic Device Description 129 acyclic extended diagnostics 138 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 147...
  • Page 154 PROFIBUS Ident Number 101 Loss of Echo (LOE) programmer explanation 121 handheld 30 programming maintenance 114 enter program mode 31 calibration schedules 50 programming LR250 cleaning 114 via handheld programmer 31 repairs 114 Page 148 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 155 SITRANS LR250 operating principles 115 overview 6 startup transition screen 28 status byte status codes 132 status codes 132 Support contact information 3 Technical Support 3 temperature de-Rating curves 123 7ML19985LT01 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 149...
  • Page 156 Notes Page 150 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 157: Lcd Menu Structure

    LCD menu structure SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS Page 151 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 158 2.4.5 ECHO SELECT 2.6.1 STATIC REV. NO. 2.4.5. 1 ALGORITHM 2.6.2 MODE 2.4.5.2 POS. DETECT 2.4.5.3 ECHO THRESHOLD 2.6.3 CHANNEL 2.4.5.4 CLEF RANGE 2.6.4 LABEL Page 152 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...
  • Page 159 3.7.3 MIN. OUTPUT FB1 3.7.4 MAX. OUTPUT FB1 3.7.5 MIN OUTPUT FB2 3.7.6 MAX. OUTPUT FB2 4. SERVICE 4.1 DEMO MODE 4.2 MASTER RESET 4.3 POWERED HOURS 4.4 POWERON RESETS 4.5 LCD BACKLIGHT 7ML19985LT01 SITRANS LR560 (PROFIBUS PA)– OPERATING INSTRUCTIONS Page 153...
  • Page 160 4.10.7 MAINT STAT 4.10.8 ACK STATUS 4.10.9 ACK 5. COMMUNICATION 5.1 DEVICE ADDRESS 5.2 PROFIBUS IDENT 6. SECURITY 6.1 REMOTE ACCESS 6.1.1 REMOTE LOCKOUT 6.2 LOCAL ACCESS 6.2.1 WRITE PROTECTION 7. LANGUAGE Page 154 SITRANS LR560 (PROFIBUS PA) – OPERATING INSTRUCTIONS 7ML19985LT01...

  • Page 161: For More Information

    Siemens Milltronics Process Instruments Inc. Subject to change without prior notice Industry Automation (IA) 7ML19985LT01 Rev. 1.0-02 1954 Technology Drive P.O. Box 4225 *7ml19985LT01* © Siemens Milltronics Process Instruments Inc. 2010 Peterborough, ON Canada K9J 7B1 Printed in Canada email: techpubs.smpi@siemens.com www.siemens.com/processautomation...

Table of Contents
