Maximale Overview; Maximale Series Configuration Chart; Maximale Features - Altronix Maximal series Installation Manual

Maximal Expandable Power System provide system designers and installers with maximum power choices and the highest
levels of versatility. They provide 12VDC, 24VDC, or 12VDC and 24VDC simultaneously via two (2) single output power
supply/chargers. Includes AC fail, low battery and battery presence monitoring. Custom enclosure facilitates up to four (4)
12VDC/12AH batteries. All interconnecting equipment must be UL Listed.
Altronix
Output Voltage Options
Model
Number
Power Supply 1 Power Supply 2
AL400ULXB2
12VDC @ 4A
Maximal11E
12VDC @ 4A
24VDC @ 3A
AL600ULXB
12VDC @ 6A
Maximal13E 24VDC @ 6A
12VDC @ 6A
24VDC @ 6A
AL600ULXB
12VDC @ 6A
Maximal33E
12VDC @ 6A
24VDC @ 6A
AL1012ULXB
Maximal35E 12VDC @ 10A
12VDC @ 10A
AL1024ULXB2
Maximal37E
24VDC @ 10A
24VDC @ 10A
AL1012ULXB
Maximal55E
12VDC @ 10A 12VDC @ 10A
AL1024ULXB2 AL1012ULXB
Maximal75E
24VDC @ 10A 12VDC @ 10A
AL1024ULXB2 AL1024ULXB2
Maximal77E
24VDC @ 10A 24VDC @ 10A
• Filtered and electronically regulated outputs
(built-in power supply).
• Built-in charger for sealed lead acid or gel type batteries.
• AL400ULXB2, AL600ULXB, and AL1012ULXB
(Power Supply Board) maximum charge current 0.7A.
AL1024ULXB2 (Power Supply Board) maximum charge
current 3.6A.
• Automatic switch over to stand-by battery when AC fails.
• Zero voltage drop when unit switches over to
battery backup (AC failure condition).
Maximal Expandable Power Systems

MaximalE Overview:

MaximalE Series Configuration Chart:

AL400ULXB2
12VDC @ 4A
---
24VDC @ 3A
24VDC @ 3A
AL400ULXB2
12VDC @ 4A
12VDC @ 4A 1
24VDC @ 3A
24VDC @ 3A
AL600ULXB
12VDC @ 6A
2
24VDC @ 6A
24VDC @ 6A
AL600ULXB
12VDC @ 6A 2
24VDC @ 6A
AL600ULXB
12VDC @ 6A 2
24VDC @ 6A
AL1012ULXB
2
2
2

MaximalE Features:

2 7.0A 5A/250V
1 7.0A 5A/250V
--- 7.0A 5A/250V
--- 6.1A 5A/250V
5A/250V
(AL600ULXB
--- 7.9A
and
AL1024ULXB2)
--- 5.2A 5A/250V
5A/250V
(AL1012ULXB
--- 7.0A
and
AL1024ULXB2)
--- 8.8A 5A/250V
• Low battery and battery presence supervision
(form "C" contact).
• Short circuit and thermal overload protection
with auto reset.
• AC input and DC output LED indicators.
• AC fail supervision (form "C" contact).
• Enclosure accommodates up to four (4)
12VDC/12AH batteries.
• Enclosure dimensions:
26" x 19" x 6.25" (660.4mm x 482.6mm x 158.75mm)
Altronix Corp.
140 58th St. Brooklyn, NY
15A/32V
California State
Fire
Marshal Approved
15A/32V
(AL400ULXB2)
---
UL File # BP6714
UL 294
UL Listed for
Access Control
15A/32V
System Units.
(AL1012ULXB)
15A/32V
(AL1024ULXB2)
15A/32V
General Signaling
Equipment
15A/32V
Evaluated to
(AL1012ULXB
and
CSA Standard
AL1024ULXB2)
C22.2
No.205-M1983
15A/32V
- 3 -
