Video Surveillance UPS
Installation Guide
Models Include:
ReServ1V
- Twelve (12) true sine wave regulated 24VAC outputs and four (4) regulated 12VDC outputs.
- 4A total supply current @ 24VAC and 2A total supply current @ 12VDC.
- PTC protected power-limited outputs.
ReServ2V
- Sixteen (16) true sine wave regulated 24VAC outputs.
- 4A total supply current.
- PTC protected power-limited outputs.
ReServ3V
- Sixteen (16) regulated 12VDC outputs.
- 8A total supply current.
- PTC protected power-limited outputs.
Rev. 081611
More than just power.
TM
Advertisement
Table of Contents
Related Manuals for Altronix ReServ Series
Summary of Contents for Altronix ReServ Series
- Page 1 Video Surveillance UPS Installation Guide Models Include: ReServ1V - Twelve (12) true sine wave regulated 24VAC outputs and four (4) regulated 12VDC outputs. - 4A total supply current @ 24VAC and 2A total supply current @ 12VDC. - PTC protected power-limited outputs. ReServ2V - Sixteen (16) true sine wave regulated 24VAC outputs.
-
Page 2: Specifications
Overview: Altronix ReServV Video Surveillance UPS units are designed to provide power for 24VAC and/or 12VDC cam- eras during normal or power outage conditions. True sine wave regulated AC outputs and/or regulated DC outputs. ReServV Series Video Surveillance UPS Configuration Reference Chart:... -
Page 3: Installation Instructions
Installation Instructions: This installation should be made by qualified service personnel and should conform to all local codes and in accordance with the National Electrical Code. Product is intended for indoor use only. This product contains no serviceable parts. 1. Mount unit in the desired location. Mark and predrill holes in the wall to line up with the top two keyholes in the enclosure. -
Page 4: Led Diagnostics
LED Diagnostics: Power Supply Board Red (DC) Green (AC1) Power Supply Status Normal operating condition. Loss of AC. Stand-by battery supplying power. No DC output. Loss of AC. Discharged or no stand-by battery. No DC output. ReServ Board LED State Unit Status –... - Page 5 Fig. 1 - ReServ1V Input Ground --- 24VDC + Unswitched 230VAC 50Hz, 2A power mains LOW BATTERY SHUTDOWN 10 11 12 13 14 15 16 12VDC 24VAC Outputs Outputs CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteires according to the instructions.
- Page 6 Fig. 2 - ReServ2V Input Ground --- 24VDC + Unswitched 230VAC 50Hz, 2A power mains LOW BATTERY SHUTDOWN 10 11 12 13 14 15 16 24VAC Outputs CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteires according to the instructions. Supervised 12VDC Rechargeable Battery 12VDC Rechargeable Battery...
- Page 7 Fig. 3 - ReServ3V Input Ground --- 24VDC + Unswitched 230VAC 50Hz, 2A power mains 1,2 V adjust 3,4 V adjust 5,6 V adjust 7,8 V adjust 9,10 V adjust 11,12 V adjust 13,14 V adjust 15,16 V adjust 1 OUT 2 3 OUT 4 5 OUT 6 7 OUT 8...
- Page 8 (267mm) (25mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIReServV E25R - 8 -...
